Custom 500W aluminium skived fin 1000mm skiving heatsinks heat sink for 5G station automotive
- Category: >>>
- Supplier: Shenzhen Ecotherm Technology Co. Ltd.
Share on (62409120094):
Product Overview
Description
Product Description
Custom 500W aluminium fin 1000mm skiving heatsinks for 5G station/automotive | ||
Product Name | Custom 500W aluminium fin 1000mm skiving heatsinks for 5G station/automotive | |
Part Number | SW0033 | |
Surface Treatment | Nature Anodized | |
Process | Skiving + CNC machining | |
Fin Thickness | 0.1mm~5mm | |
Material | Copper or Aluminium | |
Dimension | 1000mmx800mm | |
Application | 5G station/Automotive | |
Product description
Skived Heat Sinks
Specifications:
- Processing:CNC Machining,Skiving,Cross Cutting,Milling,Drillin
- Surface Treatment：anodizing/tapping/deburring/degreasing/passivation/clearing
Features:
Skived fin heat sinks can be used as an alternative to extruded heat sinks when looking for a fin density which can’t be achieved by extrusion technology. Skived heat sinks can be manufactured from either copper or aluminium and usually have 0.5mm thick fins,although fins as thin as 0.2mm are achievable. In this manufacturing technology the heat sink fins are literally carved out of the base of the Heat sink. In the machine, specially designed blades slice the surface cutting very fine and thin fins into the raw metal block at a shallow angle, the fins are then folded vertically and aligned with the previous fin. As the fins and the heat sink base are part of the same block of material, skived fin heat sinks give excellent thermal conductivity between fin and base.Skived heat sinks can also be customized with embedded heat pipes to enhance performance if required.advantages:
1.Copper- and Aluminium heatsink made from "one piece"，we can do the maximum is 1m*1m.
2.Low tooling costs.
3.High fin density possible.
