Tire press machine hydraulic press 200 ton solid tire press machine

Product Overview

Description

Tire press machine hydraulic press 200 ton solid tire press machine





Forklift Solid Tire Press Machine is a kind of solid pressure tire changers machine, used to assemble and disassemble with ring rims and tires. It is mainly used for all kinds of solid tyre disassembly and tire pressure.









Forklift solid tire press machine
Specification	Unit	YM-80T	YM-100T	YM-120T	YM-160T	YM-200T
Nominal force	Kn	800	1000	1200	1600	2000
Max system pressure	Mpa	31.5/25	31.5/25	31.5/25	31.5/25	31.5/25
Opening Height	mm	500	800	1000	1000	1200
Stroke	mm	300	300	400	600	550
Worktable	mm	500*400	600*500	1000*800	1200*800	1400*1000

 All the parameters of the Hydraulic Solid tire Press Machine can be customized, any detail please click me





1. Computer optimization structure design, machine structure, simple, economical and practical.

2. hydraulic control of forklift tire press machine using cartridge valve integrated system, reliable action, long life, small hydraulic shock, reducing the connection pipe and leakage points.

3. independent electrical control system, reliable, action objective, easy maintenance.
4. use button centralized control, with adjustment, manual and semi-automatic three kinds of operation.
5. through the operation panel selection, can achieve the process, constant pressure two forming process, and has a pressure and other functions.
6. slider of the working pressure, no-load fast down and slow travel range can be adjusted according to the needs of the process.





The tire press is a hydraulic machine customized by our company according to the characteristics of the tire industry. It is mainly used for the replacement and installation of solid tires, which is convenient for tire manufacturers and dealers to carry out tire disassembly and assembly work and improve work efficiency. The gantry column is welded by the rear wall channel steel, which has good bearing capacity, large tonnage, simple and convenient operation, high tire press-fit, high disassembly and assembly efficiency, long service life and good stability.



Internal plastic moisture-proof anti-rust packaging,
External wooden packaging,
Exclusive container transport.
Delivery Time  for High Speed Four Column Hydraulic Press Machine for Oil Filter:
Shipped in 30 days after payment

Pre-sales Service

1. Inquiry and consulting support
2. Sample testing support
3. Recommend the most suitable machine according to customer's purpose
4. Factory visiting welcomed

 After-sales Service
1. Training how to install the machine
2. Training how to use the machine
3. Warranty 1 year
4. Engineers available to service machinery oversea



Our company is located in Tengzhou City, Shandong Province, China.A domestic leading hydraulic machine production of the Holy Land.Completely dependent on first-class production process,stand out  from a large number of hydraulic machine manufacturers .Over the years, widely praised by customers at home and abroad.  We have a number of innovative patents,because more than ten years to concentrate on only hydraulic press forklift tire press machine,in the small and medium enterprises has been the leader of the brand.
