900*1200 coal steel slage rod mill iron chromite ore grinding machine
900*1200 coal steel slage rod mill iron chromite ore grinding machine
900*1200 coal steel slage rod mill iron chromite ore grinding machine
900*1200 coal steel slage rod mill iron chromite ore grinding machine
900*1200 coal steel slage rod mill iron chromite ore grinding machine
900*1200 coal steel slage rod mill iron chromite ore grinding machine
900*1200 coal steel slage rod mill iron chromite ore grinding machine

900*1200 coal steel slage rod mill iron chromite ore grinding machine

Share on:


Price:RUB 1,213,088.00
Price in USD:Details

Quantity:


Product Overview

Description

A ball mill is a type of grinder used to grind, blend and sometimes for mixing of materials for use in mineral dressing processes, paints, pyrotechnics, ceramics and selective laser sintering. It works on the principle of impact and attrition: size reduction is done by impact as the balls drop from near the top of the shell.
A ball mill consists of a hollow cylindrical shell rotating about its axis. The axis of the shell may be either horizontal or at a small angle to the horizontal. It is partially filled with balls. The grinding media are the balls, which may be made of steel (chrome steel), stainless steel, ceramic or rubber. The inner surface of the cylindrical shell is usually lined with an abrasion-resistant material such as manganese steel or rubber lining. Less wear takes place in rubber lined mills. The length of the mill is approximately equal to its diameter.
The ball mill can process barite, coal slime, potassium feldspar, tungsten carbide, copper ore, slag, hematite, white ash, gold ore, aluminum powder, high alumina porcelain, iron powder, fluorite ore, aluminum powder paste, Steel slag, quartz sand, sulfuric acid slag, barite, clinker, bauxite, ceramsite sand, etc. dozens or even hundreds of ores.
Product Paramenters
Model
Ball load(t)
Feeding size(mm)
Discharging size((mm)
Capacity(t/h)
Motor power(kw)
Φ900 x 1800
1.5
≤20
0.075-0.89
0.65 - 2
18.5
Φ900 x 3000
2.7
≤20
0.075-0.89
1.1- 3.5
22
Φ1200 x 2400
3
≤25
0.075-0.6
1.5- 4.8
30
Φ1200 x 3000
3.5
≤25
0.074-0.4
1.6-5
37
Φ1200 x 4500
5
≤25
0.074-0.4
1.6-5.8
55
Φ1500 x 3000
7.5
≤25
0.074-0.4
2-5
75
Φ1500 x 4500
11
≤25
0.074-0.4
3-6
110
Φ1500 x 5700
12
≤25
0.074-0.4
3.5-6
130
Φ1830 x 3000
11
≤25
0.074-0.4
4-10
130
Φ1830 x 4500
15
≤25
0.074-0.4
4.5-12
155
Φ1830 x 6400
21
≤25
0.074-0.4
6.5-15
210
Φ1830 x 7000
23
≤25
0.074-0.4
7.5-17
245
Φ2100 x 3000
15
≤25
0.074-0.4
6.5- 36
155 or 180
Φ2100 x 4500
24
≤25
0.074-0.4
8- 43
245
Φ2100 x 7000
26
≤25
0.074-0.4
8- 48
280
Φ2200 x 4500
27
≤25
0.074-0.4
9- 45
280
Φ2200 x 6500
35
≤25
0.074-0.4
14-26
380
Φ2200 x 7000
35
≤25
0.074-0.4
15-28
380
Φ2200 x 7500
35
≤25
0.074-0.4
15-30
380
Φ2400 x 3000
23
≤25
0.074-0.4
7-50
245
Φ2400 x 4500
30
≤25
0.074-0.4
8.5-60
320
Φ2700 x 4000
40
≤25
0.074-0.4
12-80
40 0
Φ2700 x 4500
48
≤25
0.074-0.4
12-90
480
Φ3200 x 4500
65
≤25
0.074-0.4
According to the process conditions
630
Φ3600 x 4500
90
≤25
0.074-0.4
According to the process conditions
10 00
Φ3600 x 6000
110
≤25
0.074-0.4
According to the process conditions
1250
Φ3600 x 8500
131
≤25
0.074-0.4
45.8 - 256
1800
Φ4000 x 5000
121
≤25
0.074-0.4
45 - 208
1500
Φ4000 x 6000
146
≤25
0.074-0.4
65 - 248
1600
Φ4000 x 6700
149
≤25
0.074-0.4
45 - 252
1800
Φ4500 x 6400
172
≤25
0.074-0.4
54 - 306
2000
Φ5030 x 6400
216
≤25
0.074-0.4
68 - 386
2600
Φ5030 x 8300
266
≤25
0.074-0.4
88 - 500
3300
Φ5500 x 8500
338
≤25
0.074-0.4
108 - 615
4500
Details Images
Motor and reducer
Output gate and grate screen
Grinding media : High chromium steel balls
Packing and delivery
The machine is nude packing , motor and other accessories are packing in wooden box
