Full Automatic Pet Blow Machine Auto Bottle Blowing Machine
US $13000-$30000
full automatic straight line PET bottle blowing machine
- Category: Stretch Blow Moulding Machines >>>
- Supplier: Taizhou,Huangyan,Ouge,Machine,Mould,Co.,Ltd.
Share on:
Product Overview
Description
Product Application
Full-automatic Servo Moter Blow Moulding Machine is suitable for producing PET bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle, hot fill bottle etc. Beverage bottle, medicine bottle etc.
ITEM | UNIT | AL-TP6M | ||||
瓶型规格 PRODUCT | 总功率 | Total power | PC | 6 | ||
容量 | Volume | L | 1.0 | |||
瓶口最大外径 | Max. Neck Diameter | mm | 30 | |||
瓶子最大外径 | Max.Body Diameter | mm | 80 | |||
瓶子最大高度 | Max.Bottle Height | mm | 300 | |||
理论产量 | Theoretical Output | BPH | 9000 | |||
成型组规格 MOULD | 加热间距 | Spindle Chain Pitch | mm | 38.1 | ||
瓶子间距 | Cavity Pitch | mm | 90 | |||
电力规格 ELECTRICAL | 加热功率 | Heating Power | KW | 40 | ||
伺服电机功率 | Servo motor Power | KW | 9.75 | |||
其他电机功率 | Other motor Power | KW | 4.21 | |||
总功率 | Total Power | KW | 54 | |||
电压 | Voltage | V/HZ | 220-380V/50-60HZ | |||
空压规格 AIR SYSTEM | 吹瓶压力 | Blowing pressure | Bar | 35 | ||
高压耗气量 | High pressure consuming | L/min | 7000 | |||
模具冷却水 MOULD COOLING WATER | 操作压力 | Operaating pressure | Bar | 3-5 | ||
温度范围 | Temperature range | ℃ | 10-12 | |||
流量 | Flow rate | L/min | 50 | |||
额定功率 | Cooling capacity | HP | 5 | |||
加热器冷却水 HEATER COOLING WATER | 操作压力 | Operating pressure | Bar | 3-5 | ||
温度范围 | Temperature range | ℃ | 10-12 | |||
流量 | Flow rate | L/min | 50 | |||
额定功率 | Cooling capacity | HP | 5 | |||
机台规格 MACHINE | 机台尺寸 | Size（L*W*H） | M | 4*1.3*2.3 | ||
机台重量 | Weight | KG | 4300 | |||
Products Show
Our Company
About us
Ouge company is located in the East China Sea coast, the famous "mould hometown"---- Huangyan Taizhou,Zhejiang. Specializes in the production of PET automatic and semi-automatic blowing machines, preform moulds and bottle moulds. It consists of many professional engineers with rich experience in the PET industry and high-quality staff. The main products include: PET automatic and semi-automatic blowing machines, all kinds of moulds for carbonated beverage bottles, juice bottles, alcohol drinks bottles, and cosmetic containers, PMMA lamps, PP infusion bottles, edible oil bottles, etc. Over the past several years, Ouge has always been devoting its utmost efforts to improving the technology, researching the market and developing new products to suit for all customer needs.
Our Service
Packing & Delivery
Packing Details : wooden case &plastic packaging
Delivery Details : 45 days after receive the deposit
Our Certifications
Our Exhibition
2019 VietnamPlas
2019 Chinaplas
The 126th Canton Fair
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: 45 days after receive the deposit
Q:What is your terms of payment?
A: T/T 30 as deposit,the rest should be paid before shipment.
Q: What about the lead time for mass production?
A: Honestly, it depends on the order quantity and the season you place the order. Generally speaking, production lead time is within 5 weeks.
