Nickel Free White Bronze Solution Nickel Plating Brightener

Product Overview

Description



Rolling Plating of Lead Free Nickel Free Nickel

Low Cyanide& High Temperature Resistant

Lead free and nickel free Nickel 730 process can produce a shinny and silvery white layer, which possesses features of excellent ability in wear-resisting, anti-corrosion, and high temperature endurable to 250℃ without discoloration for 30 mins, and also, high hardness (600HV0.05), low fragility, good covering, quick deposit on surface, and wide operation range, and so on. Low density of composition and LOW CYANIDE containing in the bath makes the environmental effluent treatment becomes easy and low cost. Since the additives and produced surface not contain any lead or other heavy metals, it is satisfied with the restriction on harmful metal from EU countries, America and Japan. It is suitable to be used for final color, or basic layer for sliver, gold, palladium and rhodium.

1. Makeup Method

             Composition               Rack                 Barrel

       Sodium Cyanide                    18g/L                         20 g/L

         Potassium Hydroxide(CP)       5 g/L                        6 g/L

         Copper Cyanide                      6 g/L                        6 g/L

         Tin Salt                                     10g/L                          10 g/L

         Zinc Oxide                                2g/L                                   2 g/L

         Potassium Carbonate            10 g/L                      10 g/L

         730A Brightener                    0.5 ml/L                0.3—1ml/L

         730B Complex Agent           20 ml/L                 10—30 ml/L

         730C Wetting Agent             1 ml/L                  1—2 ml/L

1. Operation Requirement

     Compositions     Standard(Rack/Barrel)        Range(Rack/Barrel)

       Metal Copper        4g/L/5g/L               3—5g/L/ 4—6g/L

      Metal Tin            5g/L/ 4g/L              12—15g/L/ 10—12g/L

     Metal Zinc            1g/L/ 1g/L             0.5—1.5g/L/ 0.5—2g/L

              Free Sodium Cyanide     5g/L/ 6g/L               10—15g/L/12—18g/L

    Potassium Hydroxide      5g/L/ 6g/L               4—6g/L/5—8g/L

   Temperature              40℃ /32℃                  35℃— 45℃/30℃— 35℃

    PH Value             12

2. Operation

Workpieces Rotation            Necessary

Filtration                                 Filter Cartridge≤10μm,At least 2-3 times an hour.

Anode Current Density          2.0 a/dm2

Deposit Rate                        Almost 0.5μm/min in the case of 2.0a/dm2

Deposit Volume                   Almost 1.5μm/min in the case of 2.0a/dm2

Layer Density                      Almost 8.5g/cm2

Load of Current per Liter

3. Supplement per 6000 a.min (Alloy weight 128mg)

Sodium Cyanide                            100g

    Potassium Hydroxide                         20g

   Copper Cyanide                             50g

  Tin Salt                                    100g

  Zinc Cyanide                                 3g

  730A Brightener                         100—300 ml

  730B Complex Agent                    200—400 ml
