ACR123U with LCD Visual USB contactless RFID Reader Writer

Share on (62412374672):


Price:$106.00 - $116.00

Quantity:


Product Overview

Description



Product Description


    ACR123U with LCD Visual USB contactless RFID Reader Writer























































































































Physical Characteristics
Dimensions (mm)Main Body: 159.0 mm (L) x 100.0 mm (W) x 21.0 mm (H)
With Stand: 177.4 mm (L) x 100.0 mm (W) x 94.5 mm (H)
Weight (g)Main Body: 281 g
With Stand: 506 g
USB Interface
ProtocolUSB CCID
Connector TypeStandard Type A
Power SourceFrom USB Port
SpeedUSB Full Speed (12 Mbps)
Cable Length1.5 m, Fixed
Contactless Smart Card Interface
StandardISO 14443 A & B Parts 1-4
ProtocolISO 14443-4 Compliant Card, T=CL
MIFARE® Classic Card, T=CL
SAM Card Interface
Number of Slots3 Standard SIM-sized Card Slots
StandardISO 7816 Class A, B, C (5 V, 3 V, 1.8 V)
ProtocolT=0; T=1
Built-in Peripherals
LCDGraphical LCD with White Backlight
Resolution : 128 x 64 pixels
Number of Characters: 16 characters x 8 lines
LED4 single-color: Blue, Yellow, Green and Red
Tapping RegionTri-color backlight: Red, Green and Blue
SpeakerAudio Tone Indication
Other Features
SecurityTamper Switch (Internal anti-intrusion detections and protection)
Firmware UpgradeSupported
Real-time ClockSupported
Certifications/Compliance
Certifications/ComplianceISO 14443
ISO 7816 (SAM Slot)
USB Full Speed
PC/SC
CCID
VCCI (Japan)
KC (Korea)
Microsoft® WHQL
CE
FCC
RoHS 2
REACH
Device Driver Operating System Support
Device Driver Operating System SupportWindows® CE
Windows®
Linux®
Solaris




The ACR123U is the USB version of the ACR123S, a cost-effective, flexible and intelligent contactless reader. It can be integrated to existing (Point-of-Sale) terminals or cash registers, to offer the convenience of a cashless payment system. The ACR123U speeds up movement in checkout counters, by enabling customers to complete payments by simply tapping their cards.


The ACR123U is equipped with a large graphical LCD that allows merchants to display messages, as well as a large tapping area with backlight, which guides customers in carrying out their payment transactions. Developed based on 13.56 MHz contactless (RFID) technology, it supports any contactless card following the ISO 14443-4 standard. It is also equipped with a large graphical LCD, as well as a large user-controllable tapping area with backlight.


    ACR123U with LCD Visual USB contactless RFID Reader Writer  .png









RFID Readers


   ACR123U with LCD Visual USB contactless RFID Reader Writer  .jpg
