Wholesale 12V 30A 360W DC Universal Regulated Switching Power Supply for CCTV LED Strip Light
- Category: >>>
- Supplier: Ninghai Yingjiao Electrical Co. Ltd.
Share on (62413522018):
Product Overview
Description
Wholesale 12V 30A 360W DC Universal Regulated Switching Power Supply for CCTV LED Strip Light
Product Description
Input: 90-264VAC 50/60Hz
Output Voltage: 5V-48V DC
Rated Power: 360W max
Approvals: CE/RoHS
Features :
1. Universal AC input/full range
2. Withstand 300VAC surge input for 5 second
3. No load power consumption<0.2W
4. Miniature size and 1U low profile
5. High operating temperature up to 70°C
6. Protections: Short circuit / Overload / Over voltage
7. Cooling by free air convection
8. Operating altitude up to 5000 meters
9. Withstand 5G vibration test
10.High efficiency, long life and high reliability
11.100% full load burn-in test
Applications:
-Industrial automation machinery
-Industrial control system
| Model: | YSI-0504000 | YSI-1203000 | YSI-2401500 | YSI-1382000 | YSI-1380200 | ||||
| Power: | 360W Max | ||||||||
| Input: | AC90-264V | ||||||||
| Output Voltage: | 5V DC | 12V DC | 24V DC | 13.8V DC | 13.8V DC | ||||
| Output Current: | 40A | 30A | 15A | 20A | 2A | ||||
| Inrush Current: | 65 Amps max. at 240VAC/50Hz,full load | ||||||||
| Leakage Current: | <0.25mA/240VAC | ||||||||
| Protections: | Short Circuit /Over Current /Over Voltage/Over temperature protection | ||||||||
| Withstand voltage: | I/P-O/P 3kVAC | ||||||||
| Working TEMP.: | -20°C-70°C | ||||||||
| EMC standards: | EN55032 class B, EN61000-3-2,3, EN61000-4-2-3,3,4,5,6,8,11, EB61000-6-2(EN50082-2)(35~150W), GB17625.1, EAC TP TC 020; GB9254 for RS-15,25,50 only | ||||||||
| Safety standards: | IEC/EN62368, IEC/EN60950, IEC/EN61558 | ||||||||
| Dimension: | 215*113*49mm | ||||||||
| Packing: | 1PC/PE BAG+INNER BOX, 10PCS/CTN, CAN BE CUSTOM | ||||||||
