5 Years Warranty Corridor Hallway Stairwell Linkable Aluminum Housing Emergency Battery Backup Led Batten Light
Product Description
| General | Name | led linear /batten light | |||
| Information | Model No. | BY-ZH-18W | BY-ZH-36W | BY-ZH-54W | BY-ZH-72W |
| Chip | 2835 0.2w | ||||
| Warranty | 3 years | ||||
| Electrical Information | Power(W) | 18W/36W54W72W | |||
| Voltage | AC100-277V 50-60Hz | ||||
| Surge protection | 2.5kv | ||||
| Driver efficiency | >90% | ||||
| Power factor | 0.95 | ||||
| Optical Information | Luminous flux(lm) | BY-ZH-18W | BY-ZH-36W | BY-ZH-54W | BY-ZH-72W |
| 1800 | 3600 | 5400 | 7200 | ||
| Luminous efficacy(lm/w) | 100 | 100 | 100 | 100 | |
| CRI | >80 | ||||
| Color temperature | 3000k/4000k/6500k | ||||
| LED quantity(PCS) | 96 | 192 | 288 | 384 | |
| Beam angle | 120° | ||||
| Mechanical Information | Housing material | Aluminum+Optical PC | |||
| Ambient temperature | -40℃~50℃ | ||||
| Working temperature | <60° | ||||
| IP Rating | IP44 | ||||
| Packaging Information | Product size(MM) | 600*72*25 | 1200*72*25 | 1500*72*25 | 2400*75*25 |
| Packaging size(MM) | 625*28*18/20pcs | 1240*28*18/20pcs | 1540*28*1820/pcs | 2440*28*18/20pcs | |
| N.W. about(KG) | 4.8 | 8.7 | 11.3 | 17.8 | |
| G.W. about(KG) | 5.1 | 9.6 | 12.1 | 20.2 | |
