Molecular Distillation is a special liquid-liquid separation technology, which is different from traditional distillation on the difference boiling point. This is a kind of distillation in high vacuum environment, for the difference of material molecular movement free path,was carried out in the heat sensitive materialor high boiling point material distillation and purification process. Short Path Distillation is mainly used in chemical, pharmaceutical,petrochemical, spices, plastics, oil and otherfields.
Model
Effective evaporation area(m²)
Cooling area(m²)
Barrel inside diameter(m²)
Constant pressure feeding funnel volume(L)
Processing flow(kg/H)
Motor power(W)
Max rotation speed(RPM)
SPD-80
0.1
0.15
80
1
0.3-4.0
200V~/140W
600
SPD-100
0.15
0.2
100
2
0.5-5.0
220V~/250W
600
SPD-150
0.25
0.4
150
5
1.0-8.0
220V~/250W
600
SPD-200
0.3
0.4
200
5
2.0-10.0
220V~/250W
600
Features
. High evaporation efficiency can reduce retention time with minimal time delay.
. Short path distillation is made of 3.3 high borosilicate glass and PTFE,
which has excellent corrosion resistance. . Main body of short path distillation is made of 3.3 high borosilicate glass, allowing thewhole process to be observed very clearly.
. High-precision distillation barrel allows the liquid to form a complete and unified thinfilm on the heated surface.
The smooth inner surfacecan avoid stick and scaling.
. Frequency conversion deceleration motor with self-cooling fan, long time continuousworking.
