Small Marble Sand Making Machine Vsi Crusher
Product Description
VSI Sand MakerMachine is a newly researched equipment, with international advanced level. Technology and modern processing equipment make it a leading role in this industry. VSI Sand Making Machine is widely used for artificial sand, in metal and nonmetal;ores,;cement, refractory material, bauxite, silicon carbide, glass material, building material.
Features
1. Advanced doublepump oil lubrication system guarantee shaft bearing lower temperature increase, longer life time, more reliable operation.
2. Main shaft is equipped with imported precision rolling bearing. It makes main shaft work stable, lengthen maintenance cycle, increases productivity.
3. Hydraulic lifting mechanism of upper cover can move away the cover easily, which saves man power during maintenance.
4. Overvibration device is equipped. There will be alarm when vibration surpasses a stipulated figure. It will stop the machine, in order to protect it.
5. Special dustproof design for main shaft bearing fully avoid dust entering bearing lubrication part, which make sure the machine work normally.
6. Special feed opening structure makes it possible that center feeding and ring feeding comes together, in order to meet requirement of different stones. In addition, this equipment can not only crush stone, but also iron.
7. Shape of material-through device is better designed, which improve the utilization ratio.
Working Principle
Raw material falls down into feed hopper, then enters impellor through central entrance hole. It is accelerated in high-speed impellor, then is thrown out at speed of 60-75m/s. When hitting impact plate, it is crushed. Final products come downwards though outlet.
Technical Parameters
| Model | VSI-7611 | VSI-8518 | VSI-9526 | VSI-1140 | |
| Capacity(t/h) | Cascade and Center Feeding | 120-180 | 200-260 | 300-380 | 450-520 |
| Center Feeding | 60-90 | 100-130 | 150-190 | 225-260 | |
| Feeder Opening Size (mm) | Soft Material | ≤35 | ≤40 | ≤45 | ≤50 |
| Hard Material | ≤30 | ≤35 | ≤40 | ≤45 | |
| Rotation Speed | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | |
| Power of the Double Motors(kw) | 110-150 | 180-220 | 264-320 | 400-440 | |
| Overall Dimension(mm) | 3700x2150x2100 | 4140x2280x2425 | 4560x2447x2778 | 5000X2700X3300 | |
| Weight (t) | 7.8 | 10.3 | 16 | 25.6 | |
| Power | 380V:50Hz | ||||
| Vibrating Sensor | Inspection Scope: 0.1-20mm/s,it can be adjusted continuously | ||||
| Thin oil lubrication station | Power of Double Oil Pump | 2×0.31kw | |||
| Safety | supply of oil; Stop automatically without oil flow or oil pressure; Water cooled; Heating start the motor in winter | ||||
| Overall Dimension (mm) | 820×520×1270 | ||||
| Power of Oil-box HeaterDimension (kw) | 2KW | ||||
