FULONGMA parking lot sweeper machine for sale
US $32000-$35000
I suzu 700p 4*2 190HP Multifunctional Sweeper and Washer Cleaner car 10tons Self Dump Road Washing and Sweeping Truck
- Category: Road Sweeper >>>
- Supplier: Hubei Wanglong Special Purpose Vehicle Co. Ltd.
Share on (62424876370):
Product Overview
Description
Isuzu 700p 4*2 190HP Multifunctional Sweeper and Washer Cleaner car 10tons Self Dump Road Washing and Sweeping Truck
Specification:
Isuzu 700P 4*2 190HP Multifunctional Sweeper and Washer Cleaner 5Tons Self Dump Road Washing and Sweeping Truck
Product Description
1. We can supply all brands of special trucks, such as Dongfeng, ISUZU, Sinotruck, Foton, Faw, north Benz(beiben), JAC, JMC, etc.
2. The drive type could be 4X2, 4X4, 6X4, 6X6, 8X4.
3. Certification: ASM, ISO, BV, SGS, CCC etc.
4. Full suction cleaning, no need to replace the brush; easy maintenance, no dust.
5. The cleaning effect is perfect, from tens of micron dust to ordinary pebbles, leaves and other debris can be effectively removed
6. With efficient filtration system
7. Improve cleaning efficiency and reduce cleaning costs: a vacuum cleaner is equivalent to the labor efficiency of more than 30 cleaners.
8. Suitable for coal plants, power plants, cement plants, steel plants, mining pavements, etc.
Product Specification
Product Description
1. We can supply all brands of special trucks, such as Dongfeng, ISUZU, Sinotruck, Foton, Faw, north Benz(beiben), JAC, JMC, etc.
2. The drive type could be 4X2, 4X4, 6X4, 6X6, 8X4.
3. Certification: ASM, ISO, BV, SGS, CCC etc.
4. Full suction cleaning, no need to replace the brush; easy maintenance, no dust.
5. The cleaning effect is perfect, from tens of micron dust to ordinary pebbles, leaves and other debris can be effectively removed
6. With efficient filtration system
7. Improve cleaning efficiency and reduce cleaning costs: a vacuum cleaner is equivalent to the labor efficiency of more than 30 cleaners.
8. Suitable for coal plants, power plants, cement plants, steel plants, mining pavements, etc.
Product Specification
| Cabin | Driving type 4x2 LHD, single row, with A/C | |||||||||||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 7600×2300×2700 | ||||||||||
| Wheel base (mm) | 4175 | |||||||||||
| Weight in KGS | Tare Weight | 7350 | ||||||||||
| payload | 4000 | |||||||||||
| Front axles loading capacity | 4000kg | |||||||||||
| Rear axles loading capacity | 7000kg | |||||||||||
| Max. driving speed(km/h) | 110 | |||||||||||
| Engine | Brand | Isuzu | ||||||||||
| Horse Power(HP) | 190 | |||||||||||
| Emission standard | Euro 4 | |||||||||||
| Gearbox | 5 forwards & 1 reverse | |||||||||||
| Tire | 235/75R17.5, 6 tires with one spare | |||||||||||
| Max. Cleaning Width | 3.5m | |||||||||||
| Sweeper Speed | 3~20 km/h | |||||||||||
| Max. Cleaning Capacity | 56000 m2/h | |||||||||||
| Max. Suction grain size | ≥110mm | |||||||||||
| Dumping angle | ≥45° | |||||||||||
| Hopper | 5000liters,double layer,Stainless steel inside | |||||||||||
| Water tank | 4000Liters | |||||||||||
| Auxiliary Engine | Model&Manufacturer | Cummins | ||||||||||
| Type | Four-injection,water-cooling,turbo-charged,diesel engine | |||||||||||
| Power | 140hp/103kw | |||||||||||
| Oil type | Diesel,share the same fuel box with chassis | |||||||||||
| Aerator | Type | High pressure centrifugal Aerator | ||||||||||
| Curb rotation speed | 2600-2900r/min | |||||||||||
| Driving model | Driven by auxiliary engine and transferred by transmission parts,clutch and belts | |||||||||||
| Water sprinkling | Main parts | Water pump,water filter,sprinkler,water box | ||||||||||
| Electrical system | Con-structure | Two batteries(in series) | ||||||||||
| Voltage | 24V | |||||||||||
| Battery model | 12-80A.H | |||||||||||
| Sweeping System | Type | 2 brushes installed between front and rear axle,driven by gerotor motor. Left and right brushes are controlled to lift up and down separately. Rear brushes and suction nozzle are gang controlled for up and down. | ||||||||||
| Sweeper Diameter | 900mm | |||||||||||
| Sweeper rotation speed | 80r/min | |||||||||||
| Sweeper angle adjustment | Forerake 4°-6°and extroversion 2°-4° | |||||||||||
| Suction Nozzle | Type | U-shaped | ||||||||||
| Nozzle diameter | 200mm | |||||||||||
| Nozzle ground clearance when operation | 5-10mm | |||||||||||
Can be installed: sprinkler, snow shovel, job monitoring, high pressure water gun.
.
Our Services
1, 12 months whole vehicle warranty
We could support you original spare parts. Besides, we can give assistance in the following days by email or telephone. If necessary, our outwork engineer could go for technical assistance.
2,We will provide customers with the mos economical design according to the loading equipment and the payload.ODM & OEM customize, professional and technical team provide you the best design , free logo print.Trailer assembled under strict quality control, any process is inspected .
3,With years of export experience along with excellent quality, advanced services and competitive prices, Chengli truck has won numerous customers' trust and support.
4,Packaging Details : nude , covered with wax, small type can be put into 20'GP OR 40'GP container , over sized can be carried by bulk carriers or ro-ro ship , or according to your requirements.
5. Model: we have sewage suction truck and sewage suction cleaning truck;
6. Drive model: 4*2, 4*4, 6*2, 6*4, 6*6,8*4;
7.Chassis brand: Dongfeng FOTON JAC FAW I-SUZU IVECO Sinotruk HOWO Shacman JMC.etc;
9. Crane tonnage: 5m3 to 200m3;
10. Right/Left hand drive, with A/C, single row or one and a half rows with sleeper.
Company Information
Packaging & Shipping
1.By cargo bulk shipment or ro-ro shipment .
2.By Flat Rack Container
Trust us
FAQ
Contact us
