Design Criteria

Point of use for filtration

Water Filtration

Filter capacity

360m³/h

Particle size

Dense > 50 microns

Filtration accuracy

50 microns

Pipe size

8’’ (DN 200)

Water temperature

5-40⁰C

Proposed Filter Specs

Proposed filter

GLOBAL VL14000-200

Filter type

Vacuum type

Filter capacity

400 m³/h max.

Pressure loss at nominal flow (clean filter)

0,17 mSS

Filtration area

14.000 cm²

Filtration accuracy

50 Mikron

Filter degign pressure & standard

10 Bar -DIN

Minimum backwash pressure

1,7 bar

Filter body material

AISI 304 stainless steel

Filter element material

AISI 316 stainless steel

Filter inlet & outlet diameter

DN 200 –(8’’ ) flange connection

Filter drain outlet diameter

DN 50- (2’’) threaded connection

Filter Operating Temperature

80^oC max.

Drain water amount at backwash

~250 litre (depends on water pressure)

Filter Body Control Panel

220 Volt & 100 watt

Al instrumentation is 24 V.

Filter content

(included in offer price)

Conntrol panel, diffrential pressure transmitter, inlet & outlet pressure indicators, 2” drain valve (elec. actuator), alarm outputs, monitoring instant diffrential pressure and number of backwashes

Design Criteria

Point of use for filtration

Water Filtration

Filter capacity

240m³/h

Particle size

Dense > 50 microns

Filtration accuracy

50 microns

Pipe size

6’’ (DN 150)

Water temperature

5-40⁰C

Proposed Filter Specs

Proposed filter

GLOBAL VL9400-150

Filter type

Vacuum type

Filter capacity

300 m³/h max.

Pressure loss at nominal flow (clean filter)

0,16 mSS

Filtration area

9.400 cm²

Filtration accuracy

50 Mikron

Filter degign pressure & standard

10 Bar -DIN

Minimum backwash pressure

1,7 bar

Filter body material

AISI 304 stainless steel

Filter element material

AISI 316 stainless steel

Filter inlet & outlet diameter

DN 150 –(6’’ ) flange connection

Filter drain outlet diameter

DN 50- (2’’) threaded connection

Filter Operating Temperature

80^oC max.

Drain water amount at backwash

~200 liters (depends on water pressure)

Filter Body Control Panel

220 Volt & 100 watt

Al instrumentation is 24 V.

Filter content

(included in offer price)

Conntrol panel, diffrential pressure transmitter, inlet & outlet pressure indicators, 1 ½ ” drain valve (elec. actuator), alarm outputs, monitoring instant diffrential pressure and number of backwashes

Design Criteria

Point of use for filtration

Water Filtration

Filter capacity

360m³/h

Particle size

Dense > 50 microns

Filtration accuracy

50 microns

Pipe size

8’’ (DN 200)

Water temperature

5-40⁰C

Proposed Filter Specs

Proposed filter

GLOBAL VL14000-200

Filter type

Vacuum type

Filter capacity

400 m³/h max.

Pressure loss at nominal flow (clean filter)

0,17 mSS

Filtration area

14.000 cm²

Filtration accuracy

50 Mikron

Filter degign pressure & standard

10 Bar -DIN

Minimum backwash pressure

1,7 bar

Filter body material

AISI 304 stainless steel

Filter element material

AISI 316 stainless steel

Filter inlet & outlet diameter

DN 200 –(8’’ ) flange connection

Filter drain outlet diameter

DN 50- (2’’) threaded connection

Filter Operating Temperature

80^oC max.

Drain water amount at backwash

~250 liter (depends on water pressure)

Filter Body Control Panel

220 Volt & 100 watt

Al instrumentation is 24 V.

Filter content

(included in offer price)

Conntrol panel, diffrential pressure transmitter, inlet & outlet pressure indicators, 2” drain valve (elec. actuator), alarm outputs, monitoring instant diffrential pressure and number of backwashes
