Our fuel dispenser is Adopting combination pump or separate pump,smaller shape and convenient maintenance.
Our fuel dispenser is Adopting painting-side for common type and stainless steel side for luxurious type .
Leading-static and Highly-hang oil pipe.
Features fueling as ration,resetting by computer and re-displaying when power cut.
Big-size aluminium nozzle booter.
Submersible pump to be optional.
Flow meter features high precision and strong reliability.
Excellent electromagnetic compatibility and strongly anti-jamming.
Be capable of connecting with central computer in gas station.
Conveniently combining and extending function.
To update IC card fuel dispenser.
Technical Parameter for our Fuel Dispenser
Ambient temperature
-25°C~ +55°C
Humidity
≤90%
Flow rate
5~60L/min or 5~90L/min
nozzle
Auto shut-off
Suction distance
6m(Vertical), 50m(horizontal)
Accuracy
±0.30%
Repeating tolerance
≤0.15%
Hose
3m(low hang), 4.5m(high hang)
Inlet pressure
≥54kPa
Outlet pressure
≤0.3MPa
Voltage
110V/220V/380V (50/60Hz)
Power
1HP(0.75kw)
Noise
≤80dB(A class)
Unit price range
0.01~999.99
single volume range
0.01~999999.99
accumulative volume range
0.01~9999999999.99
Explosion-proof signal
ExdmbIIAT3
2100 single nozzle Fuel dispenser * 4 m hose with one piece 120 fuel nozzle * 1 Bennett or Tatsuno or Tokhiem Type Flow Meter * 220 v 380 V pump * 1 Keyboard and display screen on the front * Pulser * Nozzle holder on the side * Sensor * 664 system,6 digital, 6 digital, 4 digital. or 886 system,8 digital, 8 digital, 6 digital
2100 Four nozzles Fuel dispenser * 4 m hose with one piece 120 fuel nozzle *4pcs * 1 Bennett or Tatsuno or Tokhiem Type Flow Meter *4pcs * 220 v 380 V pump *2pcs * 1 Keyboard and display screen on the front *4pcs * Pulser *4pcs * Nozzle holder on the side *4pcs * Sensor *4pcs * 664 system,6 digital, 6 digital, 4 digital. or 886 system,8 digital, 8 digital, 6 digital.
