| Plane near-field scanning frame |
According to the stroke of scanning frame:Application: used for the measurement of antenna plane near-field, driving the waveguide probe to scan in the plane according to the specified track.
Small: 1 m *1 m (15); 1.5 *1.5 m (30);
Medium: 2.5m*2.5m; 4m*4m; 3M*2m; 5m*4m;
Large scale: 8m*6m; 7m*7m; 9m*2m; 11m*6m.
Parameter / Model | Scanning Range(m) | Positioning Precision(mm) | Repetitive Positioning Precision(mm) | Flatness RMS(mm) |
YL-S2.5 X 2.5 | 2.5 X 2.5 | ±0.1 | 0.05 | 0.1 |
YL-S3 X 2.5 | 3 X 2.5 | ±0.1 | 0.05 | 0.1 |
YL-S4 X 3 | 4 X 3 | ±0.1 | 0.05 | 0.15 |
YL-S4 X 4 | 4 X 4 | ±0.1 | 0.05 | 0.15 |
YL-S6 X 1.2 | 4 X 6 | ±0.1 | 0.05 | 0.15 |
YL-S8 X 6 | 8 X 6 | ±0.2 | 0.1 | 0.2 |
YL-S9 X 3.5 | 9 X 3.5 | ±0.2 | 0.1 | 0.2 |
YL-S10 X 6 | 10 X 6 | ±0.2 | 0.1 | 0.2 |
YL-S1 X 1 X 0.1p | 1 X 1 | ±0.05 | 0.05 | 0.05 |
YL-S0.4 X 0.4 | 0.4 X 0.4 | ±0.05 | 0.05 | 0.05 |
YL-S1 .5 X 1.5p | 1.5 X 1.5 | ±0.05 | 0.05 | 0.05 |
