SAKO 3KW Solar Inverter Supports No Battery Working and WIFI Remote Control Off Grid Solar Power System Home Single LCD Display
- Category: >>>
- Supplier: Shenzhen King Sako Electronics Co. Ltd.
Share on (62430170903):
Product Overview
Description
SAKO 3KW Solar Inverter Supports No Battery Working And WIFI Remote Control Off Grid Solar Inverter
Features
1. With MPPT solar charger controller built inside.
2. Wide PV input range, can work without battery.
3. Remote&Removable LCD control module with various communication such as WIFI/RS485/RS232 optional for SUNON PLUS.
4. Smart and intelligent pure sine wave, high frequency technology,wall amounted design,light weighted and easy to operate.
5. Select-able charging current based on applications
6. Configurable AC/Solar input priority via LCD setting
7. Compatible with (LI Ion, LiFePo4 and etc.), batteries with BMS system and battery equalization
8. Auto restart while AC is recovering, auto charge and switch, unattended operation 9. Smart battery charger and management for optimized battery performance
10. High Efficient DC-To-AC Conversion.Minimizing Energy Loss and self power consumption
11. around protection functions: Overload/short circuit protection/high voltage/low battery voltage/high temperature,etc.
Specification
SUNON Plus series Smart pure sine wave Solar inverter +MPPT solar charger+AC charger inside, high frequency technology, 100% power, Configurable AC/Solar input priority via LCD setting.Wall mounted design. AC Output: 230V. Support computer monitor with RS232 interface.Max PV input: 500Vdc. Can work without battery at daytime.
Product Description
| Model | SUNON-PLUS 3K | SUNON-PLUS 5K |
| The rated power | 3KW | 5KW |
| INPUT | ||
| Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280VAC (For Personal Computers), 90-280VAC (For Home Appliances) | |
| Frequnecy Range | 50Hz/60Hz (Auto sensing) | |
| OUTPUT | ||
| AC Voltage Regulation (Batt. Model) | 230VAC ± 5% | |
| Surge Power | 6000VA | 10000VA |
| Efficiency(Peak) | 90-93% | |
| Transfer Time | 15ms (For Personal Computers), 20ms (For Home Appliances) | |
| Wave form | Pure sine wave | |
| BATTERY | ||
| Battery voltage | 24VDC | 48VDC |
| Floating Charge Voltage | 27VDC | 54VDC |
| Overcharge Protection | 31VDC | 63VDC |
| SOLAR CHARGER&AC CHARGER | ||
| Maximum PV Array Power | 4000W | |
| MPPT Range at Operation Vol. | 120-450VDC | |
| Maximum PV Array Open Circuit Vol. | 500VDC | |
| Solar Charger Type | MPPT | |
| Maximum AC Charge Current | 60A | |
| Maximum solar Charge Current | 80A | |
| PHYSICAL | ||
| Communication Interface | Removable USB/RS232/RS485/Bluetooth/Dry-contact | |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operation Temperature | 0℃-50℃ | |
new products
other Products
Company Information
Certifications
Packaging & Shipping
FAQ
FAQ
Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.
Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.
Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.
Q4: What is the warranty of inverter?
A4: One year warranty on Solar product.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
