good quality electrochromic switchable smart tint film for car
- Category: >>>
- Supplier: Anhui Noyark Industry Co. Ltd.
Share on (62430770819):
Product Overview
Description
Product Overviews
Designed to retrofit to existing transparent surfaces, self-adhesive smart switchable film by Noyark provides a simple and cost effective alternative to other switchable film technologies.
It is manufactured with 1 PDLC layer, 2 ITO films, 2 PET films and a self-adhesive cling layer on one side (peel and stick) which makes it easy to apply to both new and existing glass (no specialist installation equipment required).
A simple ON - OFF mode switches the film from being clear (transparent) to frosted (opaque).
This unique film technology also transforms any glass into a high definition rear projection screen allowing you to display corporate presentations, TV images and videos. A truly innovative product making switchable film technology accessible to everyone while giving your home or business the added WOW factor.
Self adhesive switchable smart film is available in 4 standard widths 1000mm, 1200mm, 1500mm and 1800mm with a maximum sheet length of 3000mm (suggested). Custom shapes and sizes are available and multiple pieces can be joined together to create large switchable glazed panels or partitions.
Privacy Protection and Space Partition | The smart film switches between opaque and transparent, its priority function is privacy protection, meanwhile, allows architects and contractors to provide creative design concepts on demands. |
Projection Screen | Ideal solution for a rear-projection screen with high contrast. |
Safety and Anti-explosion | Improve glass shatter resistance. |
Heat Insulation | Blocking 99% ultraviolet radiation, 98% infra-red rays, preventing fading of your floors and soft furnishings, protecting your skin. |
Sound Insulation | Blocking noise by 20% more than ordinary glass. |
Multiple Control Mode | To meet the needs of different occasions, various controls are available, such as remote control, wall switch, light sensor, voice control, mobile APP, etc. |
Item | Mode | Value | |
Optical Parameters | Visible Light Transmission | Power On | ≥85% |
Power Off | ≥60% | ||
Parallel Light Transmittance | Power On | ≥83% | |
Power Off | ≤5% | ||
Haze | Power On | ≤5% | |
| Power OFF | ≥96% | ||
Viewing Angle | Power On | >150º | |
Electrical Parameters | Operating Voltage | Power On | 48-65VAC |
Power Consumption | Power On | <4W/m2 | |
Response Time | On-->Off | <10ms | |
Off-->On | <10ms | ||
Physical Parameters | Color | / | White, blue, yellow, gray, black, etc |
Width | / | In Roll: 1/1.2/1.5/1.8m In Sheet: ≤1.8m | |
Length | / | In Roll: 30/60m, etc In Sheet: ≤3m (suggested) | |
Lifespan | / | >10 years | |
Environmental Parameters | Working Temperature | / | -35℃—+75℃ |
Storage Temperature | / | -50℃—+120℃ | |
Noyark smart film installation is very easy. Please follow below steps.
| Step 1: | Prepare the tools, like spray bottle, glass scraper, water squeegee, hard squeegee, clean cloth, foam glue/double-sided tapes, wire casing, special glass gule, caulking gun, power cable, power transformer, electric soldering iron, etc. |
| Step 2: | Prepare the smart film. |
| Step 3: | Clean the glass/window. |
| Step 4: | Clean the smart film. |
| Step 5: | Find the smart film self-adhesive layer side, remove the protective film gradually. |
| Step 6: | Paste the smart film to the glass/window. |
| Step 7 & 8: | Scrape the air bubbles out. |
| Step 9: | Wiring for the electrode part. After wiring, you can connect the cable to the power transformer to test the smart film, power on is transparent, power off is opaque. |
| Step 10: | Remove the protective film of non self-adhesive side if test result is OK. |
| Step 11 & 12: | Remove foam glue backing, then put the foam glue on the electrode area to cover the the electrode, remove the protective layer of foam glue, stick the wire casing on it, put the wire into the wire casing, use the special glass glue to seal the wire casing. |
Noyark self-adhesive smart film is widely used in Residential, Commercial, Industrial, Healthcare, Education, Hospitality, Transportation, Government and Arts & Entertainment fields all over the world..
Company Information
Anhui Noyark Industry Co., Ltd is one of the fastest growing high-tech companies, which was founded in 2004 and specialized in manufacturing non-adhesive PDLC smart film, self-adhesive PDLC smart film, smart glass and architectural film.
With advantages of wide application range, state-of-art technology, high quality, competitive prices and great after-sales service, Noyark products are widely recognized and trusted by worldwide clients, by the end of 2018, Noyark products have been exported to more than 200 countries and areas.
You’re warmly welcomed to contact us for future business relationships and mutual success!
