HTD 800 Chemical Industrial Dry Powder Bin Blender Pharma Mixing Machine

This machine has such functions as lifting, mixing and falling automatically. It can be equipped with various specifications of mixing hoppers to meet the mixing requirements of many varieties and different batches, which is the ideal equipment for total blending in pharmaceutical factories. At the same time, this machine has been widely used in pharmaceutical, chemical and food industries.

Working Principle and Characteristics

This machine mainly consists of vertical pillar, baseplate, rotation fork frame, driving system, braking system and control system. Push the mixing hopper into rotation fork frame and lock up the screw bolts; then start the control system to lift the hopper to mixing height and fix it reliably. The driving system will drive this machine to mix automatically according to the setting time and revolution speed. After the mixing finished, the rotation fork frame will stop in vertical direction and the hopper will fall to the ground automatically; then the machine stops and prints the process data. Finally, loosen the screw nuts of rotation fork frame to transfer the hopper to next procedure.

This hopper blender is a new model machine developed by our company based on widely absorbing foreign advanced technology and combining with national condition. After the mixing process finishes, the hopper can continue to lift to the technology required height for the convenience of discharging material.

This machine is reasonable in structure and stable in performance, convenient to operate, without any dead angle or exposed screw. The rotation body (mixing hopper) is at an angle of 30 degree to the rotation axis. The material in the hopper turns over along with rotation body; at the same time, it makes tangential movement along the hopper wall to produce intense rotation and high-speed tangential motion to reach the best mixing result.

This machine adopts PLC auto-control. It’s equipped with infrared safety device and discharging butterfly valve with anti-misoperation device to guarantee the production safety. The material can pass through each procedure orderly in the same container without shifting and feeding frequently to avoid cross contamination and dust pollution, not only effectively solve the problems of material loss and stratification, but also optimize the production technology, which completely meeting the GMP requirements.

Service 1

Providing photographer recording high precision video about installing, debugging and changing mould for you before shipment, cost paid by ourselves. The video helps you operate the machine better, which not provided by other suppliers.

Service 2

Different languages are available to be inputted in the touch screen, such as Russian, Arabic, French, Spanish etc., in order to help your machine operator understand and run machine smoothly.

Service 3

We will dispatch engineers to your site for machine installation and commissioning, and also do the training for your technicians.

Service 4

12 (twelve) months guarantee time. During this Warranty period, we will provide free spare parts that cause by the machine’s quality within 10 days by fast courier upon receipt of buyer’s notice. We will also provide one set of spare parts/wear & tear parts to customer along with the shipment of the machine.

Service 5

Warmly welcome suggestions from customer, to help us grow better and provide much better machines. Meanwhile, welcome to have a visit or inspection the machine before order or shipping. We'll arrange the pick up and your following schedule in our city to bring you a nice journey.

Wenzhou Liangke Machinery Co., Ltd.

Wenzhou Liangke Machinery Co.Ltd. is an enterprise specialized in the developing, manufacturing, marketing ans servicing of solid dosage production line. With a history more than ten years, our machines are widely applied in many fields, such as pharmacy, foodstuff, health care product and chemical industry. Over the years, our factory has been rated as credible unit, level A credible unit, SME of development and technology in Zhejiang Province, SME of technology in Zhejiang Province, and enterprise of technology (innovation) in Wenzhou City. Besides, with various professional domestic certificates, such as invention patent, our machines have also passed the CE certificate. Our machines win a wide market both at home and abroad, including the overseas countries and regions such as America, Europe, Oceania, South America, West Asia, Middle East and South-east Asia etc..

Our main products include the following: high efficiency wet granulator, pellet granulating and coating machine, roller compactor, fluid bed dryer, three dimensional mixer, cone mixer, bin blender, quick type cone and milling machine, and the related cleaning machine.

The main feature of our machines and services are as following:

1. With a long life based on the top-ranking raw material and electrical and mechanical parts we adopted on the machine.

2. With our patented design and technology, our machine is simple to operate , easy to clean without dead corner, and mostly importantly, safe for operator.

3. All our machines are in strict accordance with CGMP

4.We will design the machines for customer with special requirement and room layout, and we provide stable after sales service including installation, training and remote assistance.

Welcome to our factory or contact us for more information.......
