Product Overview
Description
Product Description
Purpose of drying meat
The purpose of drying is to remove water or solvent from some raw material and semi-finished products so as to facilitate the packing,transportation,storage,processing and use of material.
Meat drying machine
The meat drying machine with the hot air circulation method can choose through-flow type. The air duct adopts the through-flow type. The hot air circulation method will dry the meat product material from top to bottom or in the opposite direction, which can make the hot air pass through the meat product material because we most of the meat products are placed in a suspended manner. For example, we often see bacon, plate duck, sausages, etc.
Product Name: | Meat drying equirpment | |||
Material: | Steel / Stainless Steel | |||
Power (KW): | 4.8 | |||
Features: | Drying, Dehumidify, Fourth waste heat recovery technology, touch screen control, Programmable |
The working principle of meat drying equipment
The meat dryer can be equipped with a booster fan and a booster pipe in the drying room. Generally, the booster pipe can be installed on one side of the drying room, and one end of the booster pipe is connected to the booster fan. The booster fan can suck air through the booster pipe. The working principle is to suck in the hot air for drying meat products, which increases the pressure in the air supply chamber and the air volume of the air outlet, forming the air volume cycle of the drying room, which makes the drying time of meat products more Shorter, more energy-efficient, further improve the working efficiency of the meat product dryer, grasp these two points, the meat products will dry faster.
The applictaion of meat drying machine
The meat drying machine not only apply in sausage, ham, it also suitable in vegetable, agriculture products, fruit, noodles, tea, sludge and wood in many field.
Medicinal material dryers: Star anise dryer, Morinda officinalis dryer, Dendrobium dryer, Honeysuckle dryer,etc.
Wood dryers: Mahogany furniture dryers, Furniture paint dryers, Rose wood, Bamboo stick dryers,etc.
Agriculture products dryer: Mushroom dryer, Longon dryer, Pitaya dryer, Tobacco dryer, Pepper dryer,etc.
Food dryer: Sausage dryer, Bacon dryer, Preserved fish dryer, Noodles dryer, Rice flour dryer,etc.
Tea dryer: Pu 'er Tea, Lemon tea, Yerba mate ,Ceylon Tea, Iron Buddha, Jasmine tea,etc.
Seafood dryer: Squid dryer, Abalone dryer, Shrimp dryer, Marine dryer,etc.
Agriculture products dryer: Mushroom dryer, Longon dryer, Pitaya dryer, Tobacco dryer, Pepper dryer,etc.
Food dryer: Sausage dryer, Bacon dryer, Preserved fish dryer, Noodles dryer, Rice flour dryer,etc.
Tea dryer: Pu 'er Tea, Lemon tea, Yerba mate ,Ceylon Tea, Iron Buddha, Jasmine tea,etc.
Seafood dryer: Squid dryer, Abalone dryer, Shrimp dryer, Marine dryer,etc.
Product features
1.Safety & Environment protection：The low-temperture drying process below 80°c is fully suitable for drying.It adopts low temperture （40-80°c）fully enclosed drying mode ,no odor overlow ,no need to install complex deodorizing device.
2.Energy saving & Efficient: Using heat pump recoery technology, the closed drying mode dose not have any waste heat discharge.
3.Intelligent & Operating easily: Fully automatic operation, PLC+touch screen intelligent control,which temperature and humidity can be controlled in different time.
Size Information
Recommend Configuration
Model | Capacity | Drying room size | Trolley qty | Drying room size can be customized under your requirements. |
YK-12E | 50KG/batch | 1300X760X2400mm | 1 | |
YK-24E | 100KG/batch | 2800x960x2200mm | 2 | |
YK-72RD-ZTB-24 | 150KG/batch | 2800x960x2200mm | 2 | |
YK-72RD-ZTB-24L | 200KG/batch | 2800x960x2200mm | 2 | |
One unit YK-72RD | 400KG/batch | 4000*2400*2400mm | 6 | |
Two units YK-72RD | 800KG/batch | 8000x2400x2400mm | 8 | |
One unit YK-145RD | 600KG/batch | 5000x3300x2400mm | 8 | |
Two units YK-145RD | 1500KG/batch | 8000x3300x2400mm | 12 | |
One unit YK-290RD | 1200KG/batch | 8000x3300x2400mm | 12 | |
Two units YK-290RD | 3000KG/batch | 12000x3300x2400mm | 20 | |
One unit YK-360RD | 1500KG/batch | 10000x3300x2400mm | 12 | |
Two units YK-360RD | 4000KG/batch | 13000x3300x2400mm | 20 |
Details Images
Fan rack and fans
Trolley
Heat Pump Dryer
Polyurethane board
Temperature and humidity probe
Dehumidification fan
Trolley | ||
Material | 304 stainless steel | |
Size | 1210*870*2000mm | |
1010*870*2000mm | ||
870*610*2000mm | ||
1400*870*2000mm | ||
Tray | ||
Sort | size | |
Punching tray | 800*600*50mm | |
Solid tube edge tray | 800*600*50mm | |
Plastic tray | 800*600*50mm | |
Mesh tray | 800*600*50mm | |
Related Products
Model:YK-290RD
Click on me!
Model:YK-72RD-CH
Click on me!
Model:YK-240RD
Click on me!
Model:YK-145RD
Click on me!
Model:Yk-480RD
Click on me!
Model:YK-24E
Click on me!
Successful cases
Certifications
Product packaging
The goods are ready for Tanzania
The goods are ready for India
The goods are ready for Thailand
Packaging | ||
Size | 5.89m (L) * 2.33m (W) * 2.38m (D) | |
Weight | 3T | |
Packaging Details | The normal package is plywood box(Size: L*W*H). | |
If export to european countries,the plywood box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | ||
Packaging | ||
Size | 12.045m (L) * 2.340m (W) * 2.379m (D) | |
Weight | 5 T | |
Packaging Details | The normal package is plywood box(Size: L*W*H). | |
If export to european countries,the plywood box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | ||
