  • IPC HDW2431T AS S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built in MIC IPC HDW2431T AS S2
IPC HDW2431T AS S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built in MIC IPC HDW2431T AS S2
IPC-HDW2431T-AS-S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built-in MIC IPC-HDW2431T-AS-S2
IPC-HDW2431T-AS-S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built-in MIC IPC-HDW2431T-AS-S2
IPC-HDW2431T-AS-S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built-in MIC IPC-HDW2431T-AS-S2
IPC-HDW2431T-AS-S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built-in MIC IPC-HDW2431T-AS-S2
IPC-HDW2431T-AS-S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built-in MIC IPC-HDW2431T-AS-S2
IPC-HDW2431T-AS-S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built-in MIC IPC-HDW2431T-AS-S2

IPC HDW2431T AS S2 New Lite 4MP IR LED WDR IR Eyeball Network Camera Built in MIC IPC HDW2431T AS S2

Share on (62437123475):


Price:$45.00 - $55.00

Quantity:


Product Overview

Description



key features







IPC-HDW2431T-AS-S2
4MP WDR IR Eyeball Network Camera
> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition
> Outputs 4MP (2560 × 1440)@25/30 fps, Max. supports 4MP (2688 × 1520) @ 20 fps
> codec, high compression rate, ultra-low bit rate
> Built-in IR LED, max IR distance: 30 m
> ROI, SMART H.264, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire
> Abnormality detection: Motion detection, video tampering,no SD card, SD card full, SD card error, network disconnected, IP
conflict, illegal access, voltage detection
> Supports max. 256 GB Micro SD card, built-in Mic
> 12V DC/PoE power support
> IP67 protection



     Notice
Dear customers, choose us and you will definitely feel the value.If the same product we compete with Quality, if the same quality we compete with Price, if the same price we compete with Service, if the same service we compete with Consistency
We sell DH and HIK vision all the network products,Please contact us freely.


Camera
Image Sensor
1/3” 4Megapixel progressive CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
128 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Min. Illumination
0.008 Lux @ F1.6
S/N Ratio
>56 dB
Illumination Distance
30 m (98.43 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
2 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm
3.6 mm
Max. Aperture
F1.6
F1.6
Field of View
2.8 mm:
Horizontal 102.0° × Vertical 55.0° × Diagonal 121.0°
3.6 mm :
Horizontal 84.0° × Vertical 45.0° × Diagonal 100.0°
Iris Type
Fixed
Close Focus Distance
2.8 mm: 0.9 m (2.95 ft)
3.6 mm: 1.6 m (3.61 ft)
DORI Distance
Lens
2.8 mm
3.6 mm
Smart event
IVS
Tripwire; intrusion
Video
by sub stream)
Video Frame Rate
Main stream:
2688 × 1520 (1 fps-20 fps)
2560 × 1440 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)
Stream Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p
(1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–6144 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
Disable/Enable (4 areas, rectangle)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution.)
Mirror
Yes
Privacy Masking
4 areas
Audio
Built-in MIC
Yes
Audio Compression
G.711A; G.711Mu; G.726
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering;
tripwire; intrusion; voltage detection; security exception
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering;
generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP;
NFS; PPPoE; Bonjour
Interoperability
ON-VIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; Micro SD card (support max. 256 G); NAS; SFTP
Browser
IE
Google
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Power
Power Supply
12V DC/PoE
Power Consumption
Basic power consumption: 2.1W (12V DC), 2.5W (POE)
Max power consumption (Max resolution, Max stream, WDR, IR full intensity, IVS): 5.7W (12V DC), 6.6W (POE)
Environment
Operating Temperature
-40°C to +60°C (-40°F to +140°F)
Operating Humidity
≤95%
Storage Temperature
-40°C to +60°C (-40°F to +140°F)
Storage Humidity
≤95%
Protection
IP67
Structure
Casing
Metal + Plastic
Dimensions
100.9 mm × Φ109.9 mm (3.97" × Φ4.33")
Net Weight
0.39 kg (0.86 lb)
Gross Weight
0.52 kg (1.15 lb)


What is IP camera how it works?

An Internet Protocol camera, or IP camera, is a type of digital video camera that receives control data and sends image data via
the Internet. They are commonly used for surveillance. Unlike analog closed-circuit television (CCTV) cameras, they require no
local recording device, but only a local area network
It is can multi-platform monitor anywhere,any country and anytime .








Factory and Warehouse



How to Choose the camera resolution




What is camera PoE?

Power over Ethernet (POE) is a technology that lets network cables carry electrical power. For example, a digital security camera
normally requires two connections to be made when it is installed: A network connection, in order to be able to communicate with
video recording and display equipment.


How to choose the camera lens


                                            How the CCTV system work


Q. What's the actual products I can get?
A: Usually OEM made by Hik/DH(no logo on the products). Customs order is welcome here. Pls contact with the sales for more details for you need.
Q. What's ETA time and stock status?
A: With Sales & Support department and US/EU/AU warehouse, we provide most lines of stock products. So if stock products, the ETA is about 3-5 days, and for products with bulk quantity, the delivery time is about 2-4 weeks.

Q. Do you provide warranty for your products?
A: Yes, we promise 2 years warranty for all our products, OEM products are with 3 years.

Q.What is your method of payment?
A: T/T, Western Union, Paypal, credit card is welcomed.

Q.What is Minimum Order Quantity?
A: Sample order is welcomed, while the price is more competitive for big quantity .

Q: How to ship the goods?
A: For small parcels, we recommend to use the express, such as Fedex, DHL, Fedex, TNT, UPS etc. For bulk order, we can ship the products to your forwarder or will find a best shipping way for you.
