Lebria hot water heater solar water storage tank for home power system high quality

Product Overview

Description





Model	Capacity	Tube	Tube	Packing	Loading quantity(sets)
	(Liter)	specification	quality	size(CBM)	20'GP	40'GP	40'HQ
LEB-15	135	Φ58mm*1800mm	15	0.55	58	122	144
LEB-18	150	Φ58mm*1800mm	18	0.666	41	85	100
LEB-20	165	Φ58mm*1800mm	20	0.74	37	80	94
LEB-24	200	Φ58mm*1800mm	24	0.888	32	68	80
LEB-30	250	Φ58mm*1800mm	30	1.11	26	55	65
LEB-36	300	Φ58mm*1800mm	36	1.332	21	45	54





Inner tank Materia		Thickness: 1.2mm food grade SUS304-2B stainless steel
		Diameter: Normally 360mm
Vacuum tube		QB-AL-N/AL-58-1800 with heat pipe
Outer tank Materia		Thickness: 0.4mm galvenized steel
		Diameter: 470mm
Insulation layer material		Thickness: 55mm polyurethane integral foam
		Heat preservation: 72 hours
Frame		1.2-15mm thickness galvenized steel
Heat pipe		90mm length condensor, 14mm diameter body,thickness:0.6mm
Max. fluid pressure		0.6Mpa
Operating fluid pressure		0.6Mpa
Test pressure		1.2Mpa
Dust Proof Rubber		EPDM
Payment Method		1.30% Deposit in advance and balance should be paid before shipment based on you nominate the forwarder 2.30% Deposit in advance and balance should be paid after receiving the B/L copy



Features:

1. Adopts the best conduction performance metal- heat pipe (copper).
2. Can be used all year round in the cold climate.
3. High efficiency, rapid warming. Heat pipe in vacuum tube could transfer hot energy to cold water in pressurized water

tank rapidly.
4.The whole pressure of the system is up to 1.5kg/M2, the inlet could connect the tap water directly, the max pressure can

be 0.6Mpa.
5. No water in the tube, one tube broken don't influence the system working.
6. The design for inner tank is reasonable and scientific, which could hold 100, 000 times fatigue test without any damage.
7. Dual-purpose brackets for both flat and inclined roof.

8. The system is pressurized,it keep a constant temperature of water in the tank, avoid the problem came from water

level controller malfunction which could cause water flow out.



Advantage:



1. The pressure of hot water is pressure of tap water directly ,you can enjoy more comfortable shower.

2. Hot water that we use flow in copper coil without transferring in tank directly ,so the water is more clean and healthy.

3. There is no need to wait , you can enjoy instant hot water at any time .

4. It is suitable for some area special with bad water quality such as hard water ,impurity water etc.We only need use

high quality water in tank as a thermal source,refresh it during some time in interval.This will increase vacuum tube

heat efficiency and in ease whole system life performance.

5. Can be used all year round in the cold climate.

6. Simple structure, easy to assembly and install, diffuse flat plate reflector can be assembled easily with its module

structure.
