Product Overview
Description
Product Description
Product Name | KS0460 keyestudio Logic DC Jack Module |
Material | FR4 |
Introduction
When we design program to do experiments, we often need to use logical transformation.
The keyestudio Logic DC jack module comes with a logic conversion function that includes AND gates and NOT gates.
When in use, the toggle switch is turned to the "OFF" terminal, there is no output; when the toggle switch is toggled at the "SW1" terminal, the logic NOT gate function is implemented, and the IN1 input level and the OUT output level are opposite;
When the switch is toggled at the "ON" terminal, logic and function are implemented, and the IN1 level and the IN2 level are
combined to obtain the OUT level.
The working voltage of the module is 5V.
There are two ways for supplying power. The first way is to connect 5V power supply to GND and VCC; the aother way is to connect
the DC 5.5-15V power supply to the black DC head of the module.
The keyestudio Logic DC jack module comes with a logic conversion function that includes AND gates and NOT gates.
When in use, the toggle switch is turned to the "OFF" terminal, there is no output; when the toggle switch is toggled at the "SW1" terminal, the logic NOT gate function is implemented, and the IN1 input level and the OUT output level are opposite;
When the switch is toggled at the "ON" terminal, logic and function are implemented, and the IN1 level and the IN2 level are
combined to obtain the OUT level.
The working voltage of the module is 5V.
There are two ways for supplying power. The first way is to connect 5V power supply to GND and VCC; the aother way is to connect
the DC 5.5-15V power supply to the black DC head of the module.
