sheet pile driver electric pile driver excavator piling driver

Product Overview

Description





  Features

1. The use of special steel has the advantages of high toughness and high wear resistance

2. It is used on hydraulic excavators and uses the liquid on the excavator.

    Pressure system provides power, fast installation, convenient operation, flexible and flexible

3. A motor-driven type uses centrifugal force to reciprocate up and down to generate excitatory force.

4. Efficient, mute, piling and plucking operations

5. Original imported motor, lasting endurance, high speed, large torque, greater vibration intensity and frequency, faster

6. All the bearings used are imported from the original, with long service life

7. All key parts of the shaft are made of the same material as the core and heat treated to ensure service life.

8. It can be made into single chuck, double chuck can be adjusted, or it can be used in combination with a crane.



 Payment term:
1.L/C at Sight
2.T/T: 30% advanced payment , 70% balanced payment before shipment.
*Trade term: EXW, FOB, CNF, CIF all accepted.



Packaging Detail:

Export standard wooden pallet, wooden case or steel case.



Product parameter
model	weight	Jaw weight	Attached arm weight	max vibration  frequency	oil flow	pressure	suitable excavator
Unit	kg	kg	kg	Rpm	L/Min	kg/cm2	Ton
TD200	1450	350	500	2800	155	280	20-30
TD300	1550	400	600	2800	168	280	30-40
TD400	1650	480	650	2800	210	300	40-50
TD500	1800	550	720	2800	265	300	50-60
