Product Overview

Description



Company Introduction


Shandong Xingdou Equipment is focus on all kinds of rack and pinion driving vertical access machinery and Supply design, solution and OEM to all customers all over the world!


ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator


500kg-3000kg loading capacity passenger cum material constriction site building lift

Its main products include:
PLC construction lifts.
Low, medium, and high-speed variable frequency construction lifts.
Special purpose construction lifts, such as power plant cold water tower construction lifts, mini rack construction lifts for tower crane, and mine construction lifts.
Inclined construction lifts.
Small rack observation lift.
High-level test bed maintenance lift.
Other OEM type rack and pinion vertical lift.



Successful projects:

Our ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator have sent to more than 30 countries and get well feedbacks from them!




Product description


Common Construction ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator



Specification
Type
Lifting Capacity
Lifting Speed
Motor Power
Safety Device

Single cage without counter weight
SC100
1000Kg




33m/min
2*11Kw
SAJ 30-1.2
SC150
1500Kg
2×13Kw
SAJ 40-1.2
SC200
2000Kg
3×11Kw
SAJ 40-1.2

Twin cages without counter weight
SC100/100
1000Kg×2EA
2×11Kw×2EA
SAJ 30-1.2
SC150/150
1500Kg×2EA
2×13Kw×2EA
SAJ 40-1.2
SC200/200
2000Kg×2EA
3×11Kw×2EA
SAJ 40-1.2


Low speed Frequency ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator:


Specification
Type
Lifting Capacity
Lifting Speed
Motor Power
VFD
Safety Device


Single cage without counter weight
SC100L
1000Kg
0~33m/min    0~40m/min
2×11Kw
30Kw
SAJ 30-1.2
SC150L
1500Kg
0~36m/min     0~46m/min
2×13Kw 2×15Kw
30Kw   37Kw
SAJ 40-1.2
SC200L
2000Kg
0~40m/min     0~46m/min
2×15Kw 3×11Kw
37Kw
SAJ 40-1.2

Twin cages without counter weight
SC100/100L
1000Kg×2EA
0~40m/min
2×11Kw×2EA
30Kw×2EA
SAJ 30-1.2
SC150/150L
1500Kg×2EA
0~36m/min 0~46m/min
2×13Kw×2EA2×15Kw×2EA
30Kw×2EA37Kw×2EA
SAJ 40-1.2
SC200/200L
2000Kg×2EA
0~40m/min 0~46m/min
2×15Kw×2EA2×11Kw×2EA
37Kw×2EA
SAJ 40-1.2


 Mediaum speed Frequency system ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator:



Specification
Type
Lifting Capacity
Lifiting Speed
Motor Power
VFD
Safety device
Single cage without counter weight
SC 100 M
1000Kg
0~60m/min
3×13Kw
45Kw
SAJ 30-1.4
SC 150 M
1500Kg
0~63m/min    0~60m/min
3×15Kw 2x19Kw(87Hz)
45Kw 55Kw
SAJ 40-1.4
SC 200 M
2000Kg
0~60m/min   0~63m/min   0~70m/min      0~75m/min
2×23Kw(87Hz) 3×15Kw   3×19Kw(87Hz) 3×23Kw(87Hz)
55Kw 55Kw 75Kw 75Kw
SAJ 40-1.4   SAJ50-1.6 SAJ50-1.6 SAJ50-1.6
Twin cages without counter weight
SC 100/100 M
1000Kg×2EA
0~60m/min
3×13Kw×2EA
45Kw
SAJ 30-1.4
SC 150/150 M
1500Kg×2EA
0~63m/min   0~60m/min
3×15Kw×2EA 2x19Kwx2EA
45Kw 55Kw
SAJ 40-1.4
SC 200/200 M
2000Kg×2EA
0~60m/min    0~63m/min  0~70m/min  0~75m/min
2×23Kw×2EA(87Hz)3×15Kw×2EA 3×19Kw×2EA(87Hz)3×23Kw×2EA(87Hz)
55Kw 55Kw 75Kw 75Kw
SAJ 40-1.4 SAJ50-1.6 SAJ50-1.6 SAJ50-2.0


Hight speed Frequency ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator:



Specification
Type
Lifting Capacity
Lifiting Speed
Motor Power
VFD
Safety device
Single cage without counter weight
SC 200 H
2000Kg
0~80m/min  0~96m/min
3×26(87Hz)     3×18.5(87Hz)
 90Kw  110Kw
SAJ 50-2.0
Twin cage without counter weight
SC 200/200 H
2000Kg×2EA
0~80m/min 0~96m/min
2×3×26(87Hz) 2×3×18.5(87Hz)
90Kw×2EA 110Kw×2EA
SAJ 50-2.0


Completed safety measures for ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator

1. Equipping with Anti-falling safety device governor
2. Electrical an Mechanical interlock: Door safety switches, Slack rope switch
3. Safety hook
4. Upper and bottom limit switches, trap door limit switch
5. Overload protector
6. Bottom Buffer
7. Level Calling system and auto leveling device to be choose.
8. Ramp door for (Ex.door of cage).




XINGDOU is professional manufacturer and exporter for ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator

1. 15 years more manufacturing experience and 12 years explore foreign market standard.

2. Zero accident record.

3. Best price offered with special discount to develop oversea market, high quality you can enjoy.

4. High speed response with sales and after-sale service.

5. Welcome agent or distributor with most attractive profit and long last cooperation partnership.



Manufacturing Technique






Main parts of Frequency system series ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator

1.Standard cage inner size: 3000×1500×2200mm(L×B×H) or OEM dimension is avaliable

2.Cage Length can be OEM: 1000~4800 mm
3.Mast section size: 650×650mm
4.Maximum Lifting Height: 450m
5.Power Source: 220V~380V~480V,50Hz/ 60Hz



Cage& Cabin.

The cage can be made according to customers requirement. small or big type all ok for us.

Mast section.

different type of mast section we can provide, like 650*650*1508mm, 650*200*1508mm, 650*1508 flat type, 650*900*1508mm, 450*450*1508mm, 800*800*1508mm type and so on.

Cage steel frame.

 All steel frames are welding fixed inside Jig to keep each product according to technique requirement



Enclosure: different type can be chosen like wire mesh materials, steel punched type, ex-metal plate type...

Driving machinery is very important , it will influence the smoothly and steady running, we pay much more attention to each details.

All electrical part are chosen by us, and schneider brand is our standard type for customer..., test and inspection inside factory must be taken before loading.



Our Advantages


Before-sale services
As a specialist of ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator For reasonable request, we always try our best to meet customer' requirements as much as possible,including catalogue, price list,some technical information, the relevant certification materials, and product inspection information.




After-sale services
Shandong Xingdou Intelligent Equipment Co.,Ltd, a professional manufacturer of ISO & CE SGS Approved discount 2 ton building lift construction passenger elevator. In the country has 26 overseas offices, the country has nearly 50 sales and aftersales service men outlets, establish a sound system of the service network. Relying on well information management systems, comprehensive training system, to achieve "customer-centric, implementing overtime and premium services" service goals.
Service brand connotation.

1. Service slogan: Compass service always and everywhere.
2. Spirit of service: Depending on the customer's time is more valuable than gold.
3. Service Icons explanation: People on behalf of staff, hand tools, services in the world.
4. Service overall purpose: to create value for our customers.
5. Service objectives: customer-centric, implementing overtime and premium services.
6. Service requirements: simple and comprehensive and timely initiative.
