Slitting Box wrapping packing slotting die cutting paper lamination carton filling machine
- Category: >>>
- Supplier: Guangzhou Ming Na Packaging Machinery Co. Ltd.
Share on (62442528126):
Product Overview
Description
Product Details
Product Details
Parameters:
Model | MN100 | |
Power Supply | AC380V, 3Phase, 50HZ | |
Box
| Quality Requirement | 250-450g/ m3 Base on the size of carton |
Dimension Range (L×W×H) | L(50-250)mm × W(20-170)mm × H(15-100)mm | |
Leaflet
| Quality Requirement | 55-70 g/m3 |
Unfolded Leaflet Specification (LXW) | (100-260)mm x(100-190mm | |
Fold Range(LXW) | (1-4) fold | |
Compressed Air
| Work pressure | 0.5-0.8 Mpa |
Air Consumption | 120-160L/min | |
Overall Dimension( L x W x H) | 3100x1400x1800mm | |
Motor Power: | 1.5KW | |
Noise | ≤70dB | |
Speed | 30-100 Boxes/ Min | |
Environment Temperature | 25±10℃ | |
Weight | 1200KG | |
Features:
1.Automatic opening (sucking) box, folding instructions, cutting, feeding, batch number, sealing box,
detection and rejection device.
2.PLC programmable control system, man-machine interface display operation, more clear and
simple, stepless frequency control.
3.Servo/stepper motor and touch screen, Well-known brand electrical components, stable and
reliable performance.
4.Main drive of automatic cartoning machine has overload protection device, safe and reliable
5.Automatically remove the packaging products that lack packaging or lack of leaflet to ensure the
quality of packaging products. uses automatic detection and tracking system of photoelectric eye,
empty package or the product supply is not in place, will not feed cartons, max save packaging
material. No products, machine will run empty, not push product; have product no packing cartons,
machine will stop working automatically.
6. With fault display, alarm and finished product counting functions, easy to maintain and handle
faults.
7.Various automatic feeders and conveyors and other devices are optional according to customer
requirements.
8.Hot melt machine: hot melt adhesive spray seal or design hot melt adhesive brush device.
9. Can achieve linkage with aluminum plastic packaging machine, pillow packaging machine, filling
machine, soap making machine, inkjet printer (or monitoring code system), labeling machine, online
weighing instrument, three-dimensional packaging machine, heat shrink packaging machine, belt
strapping machine to combine production lines.
Product Applications
It is suitable for pharmaceuticals, food, household chemicals, hardware and electrical industries for
the packaging of blisters, bottles, vials, pillow packs, toothpaste, ect.
FAQ
Q1: Are you a factory or trading company?
A1: We are a factory specialized in bag / tube / powder / liquid pacakging machinery. Such as comestic sealing
filling machine, three dimension wrapping machine, cellophane overwrapping machine, powder filling machine,
labelling machine, code inkjet printer and so on.
Q2: Where is your factory location? How can I visit there?
A2: Locates in 1st Floor, Building A, No. 38, Nanpu Street, Luopu Road, Panyu District, near to Guangzhou
South Railway Station, welcome to visit our factory.
Q3: How can I choose the machine I needed?
A3: Please contact with us andlet us know the packaging type, packaging material.According this,we recommend the suitable machine for you.You can also send your meterials to us then we can use our machine to make samples according to your demand.
Q4: What’s the guarantee if we purchase from you?
- One year warranty time from the delivery date , we can repair and replace parts for free in one year.
- Technical support in 24 hours online, TM, Skype, E-mail, solving the relative questions in time.
- Life time free maintenance service.
- Free training course at our factory with professional engineers.
- We provide the consumable parts at agent price when you need replacement.
Q5: Will you help us to install the machine and train us to operate if we purchase your machine?
A5: We will install everything before we arrange shipment, and the our machine is very easy to operate, we will
offer operation vedio and user manual for your reference, and welcome to our factory to learn the cellophane
overwrapping machine, technical support will online in 24 hours.
Company Information
Guangzhou Ming Na Packaging Machinery Co., Ltd, a modern sole proprietorship located in Guangzhou, is a
professional packaging machinery manufacturer. We are engaged in R&D, design, manufacturing and sales as
well as after-sales service in pacakging machine industry for 15 years. We also has abtained the ISO900:2000
international quality system certification and the approval of relevant departments in China.
We are well known for our superior quality and service in the field of automatic packaging machines. Our main
products are including film sealing shrink wrapping machines, tube fiilling sealing machine, 3D transparent
callophane packaging machines, paste & powder filling machines, conveyor system, code inject printers and so
on, which are widely used in a lot ofindustries, such as foodstuff, daily chemicals, medicine and pesticides. And
Our machines have exported to more than 100 countries and regions including East Asia, Southeast Asia,
Europe, America and the Middle East. In addition, we formed a complete sales and customer service network in
China to ensure after-service.
