125ton 175ton 200ton 225ton 250ton 300ton 350ton Water cooling tower

Project

Content

Data

Notes

Basic

Data

Cooling tower type

Counter flow circular cooling tower

Ton

Cooling tower Model

KWT-125

Standard

Circulating cooling water flow

97.5m³/h

In /Out temperature

40℃/30℃

Ambient Dry/Wet ball Temp.

31.5℃/28℃

Refrigerating capacity

390,600kcal/h

454KW

Noise value

65.5dB(A)

Away tower 16M

Power supply

380V/3P/50Hz

Water quality

PH value=6-8

Design

Data

Air-water ratio

0.61kg/kg

Flying water loss

≤0.02%

Evaporating water loss

≤0.833%

Net weight

550kg

Application weight

1,650kg

Fan

Data

Fan type

Axial flow

Air volume

48,000m³/h

Fan speed

720r/min

Fan leaf diameter(F)

 1,450mm

Fan leaf number

4 Pieces/Set

Rotor type

Direct rotor

Motor speed

960r/min

Motor power

2.50 kW

Motor start method

Direct start

Main

size

Tower diameter(F)

2,700mm

Tower height(H)

2,400mm

In/out tube size(DN)

125mm/125mm

Overflow/drain pipe size(DN)

25mm/25mm

Automatic hydration size(DN)

15mm

Material

Motor

Hermetic waterproof type

Fan

A.B.S

Shell

Glass steel F.R.P

High-quality

Basin

Sprinkler system

 P.V.C

Film

P.V.C

Flame retardant

Float valve

A.B.S

Inlet system

P.V.C
