RGX LED Screen Shenzhen NEW Tech P1.5 P1.6 P1.8 P1.9 4K Ultra High Definition LED Display
- Category: >>>
- Supplier: Shenzhen RGX Electronics Co. Ltd.
Share on (62443846129):
Product Overview
Description
P1.5 P1.6 P1.8 P1.9 4K Ultra High Definition LED Display
Technical parameters
RGX Small Pixel Full Color LED Module Specifications
| Unit Module Specifications | ||||||
| Pixel Pitch | 1.25 mm | 1.56 mm | 1.667 mm | 1.875 mm | 1.904 mm | 1.923 mm |
| Pixel Configuration | 3in1 (1R1PG1B) | |||||
| Module Size(MM) | 200*150 | 200*150 | 200*150 | 240*120 | 160*160 | 200*150 |
| Module Resolution(Dots) | 160*120 | 128*96 | 120*90 | 128*64 | 84*84 | 104*78 |
| Module Weight(Kg) | 0.3 | 0.3 | 0.3 | 0.31 | 0.25 | 0.3 |
| Package LED Mode | 1010 | 1010 | 1010 | 1515 | 1515 | 15 |
| Max Power(Watt) | 22 | 21 | 20.5 | 19 | 18 | 17.5 |
| Pixel Density(Dots/SQM) | 691'200 | 641'025 | 360'000 | 284'444 | 275'625 | 270'422 |
| Driving Method | Constant Current Driving | |||||
| Scan Method(Scan) | 1/30 | 1/32 | 1/30 | 1/32 | 1/28 | 1/26 |
| Interface Way | HUB 75 | |||||
| Brightness(CD/SQM) | ≥ 1500 | |||||
| Safety Standard | CCC,FCC,ROHS,TUV,CE,ETL,BIS..... | |||||
| Unit Cabinet Specifications | ||||||
| Cabinet Size(MM) | 400*300 | 400*300 | 400*300 | 480*480 | 480*480 | 400*300 |
| Power Supply Mode(Per Cabinet) | 5V60A | 5V60A | 5V60A | 5V60A | 5V60A | 5V60A |
| Cabinet Resolution(Dots) | 320*240 | 256*192 | 240*180 | 256*256 | 252*252 | 208*156 |
| Optimal Viewing Distance(M) | 1-100 | 1.5-150 | 1.6-160 | 1.8-180 | 1.9-190 | 1.92-200 |
| Optimal Viewing Angle | Horizontal angle: 160 degree; Vertical angle: 140 degree | |||||
| Environment Temperature | Storage: -40 degree ~ +85 degree; Work: -20 degree ~ +60 degree | |||||
| Relative Humidity | 10% ~ 95% | |||||
| Current | ≤ 20mA (single LED) | |||||
| Issued by: RGX Technology Division. | ||||||
Product Description
Small pixel P1.56 HD indoor led module 200x150mm with smd 1010 Nationstar brand chips
Small Pixel Pitch P1.56 HD LED Display Indoor RGB Full Color led video panel
P1.56 indoor led display projects
P1.56 Ultra fine pixel pitch led screen brings video content to life
Flicker free broadcast with exact full HD and 4K picture
No sweat service with plug-n-play module and core design
Perfect Calibration , build led video wall big and save
HOT LED screen
Pop Sale
Hot products -indoor & outdoor RENTAL led display .
pls click it to get more info if you are doing rental business in your market.
price is flexible to quantity.
PLS contact me for more informatin on other products.500x500mm led video panels is widely used as rental items.
