Non woven geotextile felt fabric 100 1000g/sqm vertical garden

Product Overview

Description

 Non woven geotextile felt fabric 100-1000g/sqm vertical garden

Introduction:

Geotextiles are permeable nonwoven fabrics used to separate,filter,reinforce, protect or drain.Geotextiles allow filtration or separation of granular layers in roads and rail applications,used to protect membranes in landfill applications,used in coastal defence applications and used in landscaping to protect surfaces and structures from weeds and root growth.

Specifications	100	150	200	250	300	350	400	450	500	600	800	Remarks
Deviation of mass per unit(%)	-6	-6	-6	-5	-5	-5	-5	-5	-4	-4	-4	-
Thickness(mm≥)	0.8	1.2	1.6	1.9	2.2	2.5	2.8	3.1	3.4	4.2	5.5	-
Deviation of width(%)	-0.5	-0.5	-0.5	-0.5	-0.5	-0.5	-0.5	-0.5	-0.5	-0.5	-0.5	-
Tensile strength(KN/m≥)	4.5	7.5	10.0	12.5	15.0	17.5	20.5	22.5	25.0	30.0	40.0	Longitudinal Horizontal
Break elongation ratio(≤%)	40-80											-
CBR bursting strength(KN≥)	0.8	1.4	1.8	2.2	2.6	3.0	3.5	4.0	4.7	5.5	7.0	-
Equivalent opening size090(095)mm	0.07-0.2											-
Tearing strength (KN≥)	0.14	0.21	0.28	0.36	0.42	0.49	0.56	0.63	0.70	0.82	1.10	Longitudinal Horizontal
Property	High strength,Anti-acid and alkali,Abrasion resisting,Flexibility,and easy for construction.
Size of package	Width 1-6m,length 50-100m(or as request)

 Application:

(1) Drainage in the earth dam or earth embankment behind the impervious geomembrane or beneath the concrete cover.n
(2) Eliminate seepage around the tunnel, reduce the external pressure of the lining and the seepage around the buildings.non woven geotextile
(3) Drainage of foundation of artificial fill foundation.
(4) Strengthening of weak foundation in highway (including temporary roads) railway, embankment, earth-rock dam, airport, sports ground, etc.
