Features:
1.Mirrored Aluminum dial plate.
2.Overload and mis-used protection via two fuses, oxide varactordiodes.
3.Robust protective holster alongside.
4.20KΩ/ DC& 9 ,KΩ/V AC input sensitivity.
5.Adjustable back tilt device with hook-up designIdeal for using in the fields of lab, school, home applications andmore.
Descriptions:
1.Ideal for using in the fields of lab, school, home applications and more.
2.Battery:1.5V AAx2pcs and 9V(NEDA1604) x1pcs(not included)
Specifications:
Model:MT-2018
Measuring Voltage Range:
0.1/2.5/10/50/250V+/-3.0%FSD, 1000V+/-4.0%FSD
AC Voltage:10/50/250V ±4.0%FSD ,1000V ±5.0%FSD
Measuring Current Range:
50u/2.5m/25m/250mA+/-3.0%FSD, 10A+/-4.0%FSD
Measuring Resistance Range:1 / 10 / 100 /1K / 10K
Measuring Capacitance Range:0.025-0.25-25uF(C2), 2000uF(C1)
DCV:0-0.1-2.5-10-50-250-1000V
ACV:0-10-50-250-1000V
DCA:0-0.05-2,5-25-250mA
Operating Temperature:0 - 50 °
Battery check:1.5V/9V(not included)
Item weight:296g
Item size:158x106x40mm
Package informations:
Package weight: 449g/15.80oz
Package Size:165X142X62mm/6.50 x5.59 x2.44in
Polybag Package
Package included:
1 x Multimeter
1 x test leads
1 x manual
| | ±(1.0%+10d) |
| 60/600mA ±(1.0%+10d) |
| 6A/10A ±(1.2%+10d) |
| Alternating current (A) | 600μA/6000μA ±(1.5%+10d) |
| 60/600mA ±(1.5%+10d) |
| 6A/10A ±(2.0%+15d) |
| Resistance (Ω) | 600Ω ±(0.8%+5d) |
| 6/60/600K/6MΩ ±(0.8%+4d) |
| 60MΩ ±(1.2%+10d) |
| Frequency (Hz) | 100/1000Hz ±(0.5%+4d) |
| 10K/100KHz ±(0.5%+4d) |
| 1M/30MHz ±(0.5%+4d) |
| Capacitance (μ F) | 40nF±(5%+30d) |
| 400nF/4μF/40μF±(3.5%+8d) |
| 200μF±(5.0%+10d) |
| Temperature (C) | (-20C~400C) ±1.0+50d |
| (400C~1000C) ±1.5+15d |
| Temperature (F) | (0F~750F) ±(1.0+5d) |
| (750F~1832F) ±(1.5+5d) |
| Short circuit peak | Yes |
| Diode test | Yes |
| Transistor test | Yes |
| Data retention | Yes |
| Maximum / minimum measurement | Max / min |
| Relative value measurement | Yes |
| Duty cycle measurement | 0.1%~99.9% |
| PC Link | USB |
| Automatic shutdown | Yes |
| Battery low voltage indication | Yes |
| Input warning | Yes |
| EN61010-1 security specification CAT II /CAT III | CAT II 1000V |
| Battery | 1.5V AAA× 2. |
| Dimensions (D× W× H) mm | 192×95×48 |
| Weight (g) | 390g |
