12mm Mounting Dimension IP67 Waterproof Protection NO Stainless Steel Push Button Switch
12mm Mounting Dimension IP67 Waterproof Protection NO Stainless Steel Push Button Switch
12mm Mounting Dimension IP67 Waterproof Protection NO Stainless Steel Push Button Switch
12mm Mounting Dimension IP67 Waterproof Protection NO Stainless Steel Push Button Switch
12mm Mounting Dimension IP67 Waterproof Protection NO Stainless Steel Push Button Switch
12mm Mounting Dimension IP67 Waterproof Protection NO Stainless Steel Push Button Switch
12mm Mounting Dimension IP67 Waterproof Protection NO Stainless Steel Push Button Switch

12mm Mounting Dimension IP67 Waterproof Protection NO Stainless Steel Push Button Switch

Share on (62448084044):


Price:$0.95 - $1.10

Quantity:


Product Overview

Description



Product Description


Specifications
Rating
2A 36VDC
Mounting Hole Size
Φ12MM
Contact arrangement
1NO
Operating Type
Momentary
Torque
5-14N.m
Mechanical life
1000000 cycles
Electric life
200000 cycles
Contact resistance
50MΩ Max
Insulation resistance
1000 MΩ min.@500 VDC
Dielectric strength
2000 VAC
Operating temperature
-20ºC to +55ºC
Operating force
4N
Total travel
≤2mm
Saling/protection
IP67
Typical applications
Control panels including car park and traffic light
Industrial instruments
Lifts/escalator
Communication equipment
Alarm,safety and ecurity systems


NOTE: Specifications and Materials listed above are for switches with standard options. For information on specific and custom switches, Please feel free to contact us.
