Technical parameters: 1. Rated working voltage: 3.6V 2. Working voltage range: 2.5-5V (the higher the voltage, the greater the torque and the shorter the service life) 3. No load working current under rated working voltage: < =25mA (23 ℃under normal temperature) 4. Locked rotor current under rated working voltage: about 550mA (320motor) 5. Output torque under rated working voltage: ≥ 1.8N.m 6. On (off) time under rated working voltage: ≤ 8s 7. Reduction ratio: 1600:1 (applicable to dn15-20) 8. Definition of line sequence:
I: Blue (in place switch signal, open valve)
II. White (in place signal common terminal)
III: Yellow (in place switch signal, valve closing)
IV: Red(positive)
V: Black(negative) (due to the different installation and use directions of the customers, sometimes it is the opposite between opening and closing, which needs to be determined by the customers themselves according to the situation.) 9. Waterproof grade: 0
Company Profile
Cixi Kaiye Electrical Equipment Co., Ltd. is a professional manufacturer of smart water meters and HVAC valve actuators since 1991. The factory area over 28,000 square meters. It has produced hardware and plastic products about 30 years. Products are popular in both overseas and domestic market. Kaiye participated in the research and development of the actuator over 10 years. The actuators are suitable for various smart water meters and HVAC valves, and have deep cooperation with domestic water meter enterprises.
The actuators on the metal gear processing production, with small current, low energy consumption, low noise, long service life, long torque and many other advantages. Can meet the needs of various smart meter manufacturers. We also have a professional R&D team, according to customer requirements to provide professional customization.We welcome customers to contact us for future business relationships and mutual success.
