China 4x2 Tractor Trucks 375HP prime mover tractor truck with good price
China 4x2 Tractor Trucks 375HP prime mover tractor truck with good price
China 4x2 Tractor Trucks 375HP prime mover tractor truck with good price
China 4x2 Tractor Trucks 375HP prime mover tractor truck with good price
China 4x2 Tractor Trucks 375HP prime mover tractor truck with good price
China 4x2 Tractor Trucks 375HP prime mover tractor truck with good price
China 4x2 Tractor Trucks 375HP prime mover tractor truck with good price

China 4x2 Tractor Trucks 375HP prime mover tractor truck with good price

Share on (62455358595):


Price:

Quantity:


Product Overview

Description


Product Description
Engine
Model
SW6D18 375
Description
German tech, AVL developed,
mechanical type, diesel fue
Type
Inline, six-cylinder, four-valve,
water-cooled wet cylinder liners,
turbocharged and intercooled
Rated power
276kw/1900rpm
Max. torque
1720N.m/1250rpm
Displacement
9.84 L
Main Technical Specification
Kerb weight
7900kg
Peak traction capacity
40000kg
Max.traveling speed
104km/h
Min. turning radius
4808mm
Grade ability
30%
Min.ground clearance
255mm
Approach angle
19°
Departure angle
45°
Fuel tank capacity
500L
The fifth wheel
JOST2.0"
Fuel consumption
32L/100km
Dimensions
Overall size(L×W×H)
5850×2495(2975)×3950mm
Wheel base
3400mm
Tread(F/R)
2065/1860mm
Overhang(F/R)
1495/1020mm
Axle And Tyre
Front axle capacity
7.5 ton
Front axle type
Disk
Rear axle capacity
16 ton
Rear axle type
Drum
Ratio
3.876
Tyre size
12R22.5
Steering System
Driving position
Left hand drive
Type
Power steering
Transmission System
Type
ZF tech mechanical transmission with
synchronizer and sevo,16 forward & 2 reverse
Ratio
Forward 1
15.2
Forward 2
11.6
Forward 3
10.4
Forward 4
8
Forward 5
7.46
Forward 6
5.73
Forward 7
5.31
Forward 8
4.07
Forward 9
3.72
Forward 10
2.86
Forward 11
2.56
Forward 12
1.96
Forward 13
1.83
Forward 14
1.41
Forward 15
1.3
Forward 16
1
Reverse 1
12.3
Reverse 2
9.41
Clutch And Brake
Clutch
German SACHS
ABS
German WABCO
Service brake
Foot operated compressed air
braking system,two circuits,front/rear distribution
Parking brake
Hand operated
spring brake system,
brake force applies on the rear axle
Auxiliary brake
Exhaust brake
Emergency brake
Two circuits,
front/rear distribution
Electric System
Batteries
24 Volt/165Ah
System voltage
24V
Suspension
Front suspension
9 semi-elliptic leaf spring
Rear suspension
9+6 semi-elliptic leaf spring
Product Show
