Factory Price High Quality OEM ODM Analog Autofocus Starlight 1080P USB Sony Sensor Board UVC Camera Module for for Medical/ATM
- Category: >>>
- Supplier: Htw Tech Limited
Share on (62456937706):
Product Overview
Description
Product Description
Product Name | UVC USB Camera Module |
Model | TT-UVC2M29 |
Function | Star light USB camera ,Support Audio |
Major Features:
Color 1/2.7 Sony Star Light Sensor
2.0mp 1080P
6mm, 3.6mm, 2.8mm, 1.6mm, AF Lens Optional
H.264 and MJPEG compression format output.
Frame rate 30fps
4pin Cable with USB Connector
Compatible with Standard UVC Driver
Suitable for further development with embedded systems.
Suitable for video surveillance and any image processing Device
For Medical Equipment, Telescope, ATM Machine, Industrial Equipment, Kiosk and so on
2.0mp 1080P
6mm, 3.6mm, 2.8mm, 1.6mm, AF Lens Optional
H.264 and MJPEG compression format output.
Frame rate 30fps
4pin Cable with USB Connector
Compatible with Standard UVC Driver
Suitable for further development with embedded systems.
Suitable for video surveillance and any image processing Device
For Medical Equipment, Telescope, ATM Machine, Industrial Equipment, Kiosk and so on
Product Specifications
Model | TT-UVC2M29 |
Sensor | 1/2.7” SONY Sensor |
Effective Pixels | 1920(H)*1080(V) |
Image format | H.264 and MJPEG |
Resolution and frame rate | 1920*1080 MJPEG@30fps |
S/N | 50dB |
WDR | 80dB |
Minimum illumination | 0. 1lux |
Shutter | Electronic rolling shutter / Frame exposure |
Interface | USB 1.1 and USB 2.0 High Speed |
Drive Protocol | USB Video Class (UVC) |
AEC | Support |
AWB | Support |
AGC | Support |
Audio | Support |
Adjustable Parameters | Brightness, Contrast, Color, Saturation, Hue, Sharpness Gamma, White Balance, Backlight, Contrast, Exposure, Screen Flip |
Lens | 6mm/3.6mm/2.8mm/1.6mm/AF lens |
Systems Support | WinXP/Vista/Win7/Win8 Linux with UVC (above linux-2.6.26) MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC |
Power Output | DC 5V |
Working Current | 200mA~250mA |
Operating Temperature | -10～50℃ |
Storage Temperature | -20～60℃ |
Board Size | 32*32mm |
Weight | 80g |
