Product Overview

Description


Product Description
Item/Model Specification
Unit
ECOCUT-40
Input power/Frequency
V/HZ
220/50-60
Rated Input Current
A
25.2
Rated Input Power
KVA
5.5
No Load Voltage
V
270
Current Range
A
15-40
Duty Cycle
%
35
Cutting thickness
mm
6-10
Arc starting method
HF arc starting
Insulation Class
H
Air pressure
Mpa
0.3-0.5
Gas flow
L/min
50
Power Factor cos
cos￠
0.93
Efficiency
η
85%
Machine Dimension
cm
32*12*23
External Dimension
cm
36.7*19.8*27.5
Net Weight
Kg
4.9
Gross Weight
Kg
7.5
Protection Class
IP21S
Cooling
fan
FEATURES
1）Adopt new IGBT high power inverter device with a inverter frequency of 45KHZ and fast dynamic response.
2）Supports high frequency
arc starting function with fast cutting speed, narrow seam, smooth incision, small deformation.
3）With internal lag air supply time function
4）High cost performance and strong market competitiveness.
5）The maximum cutting thickness is 15mm
6）Suitable for cutting ordinary carbon steel, low alloy steel, stainless steel and other thin plates.
