Product Overview
Description
ultra-low temperature cryogenic grinder freezing pulverizing machine for plastic herb food fruit
Product Description
Product structure
The product structure consists of a pre-cooled silo, a crushing chamber, a cyclone separator, a liquid nitrogen tank, a control cabinet, and an automatic feed (discharge) mechanism.
Working Principle
Liquid nitrogen is used as a cold source. The material to be pulverized is cooled at low temperature to achieve embrittlement and easy to pulverize. After entering the pulverizer cavity, the material rotates at a high speed through the cutter head. Repeated impact, collision, shear, friction and other combined effects can achieve the crushing effect. It can crush materials that cannot be crushed at normal temperature. The high output and high mesh number (adjustable) ensure that the physical properties of Chinese medicinal materials remain unchanged.
Technical Parameters | ||||||
Model | WF-200 | WF-350 | WF-450 | |||
Studio diameter(mm) | 200 | 350 | 450 | |||
Power(kw) | 11.25 | 43.25 | 54 | |||
Working medium | Liquid nitrogen | Liquid nitrogen | Liquid nitrogen | |||
Operating temperature(℃) | ≥—196 | ≥—196 | ≥—196 | |||
Fineness(mesh) | 10-500 | 10-500 | 10-500 | |||
Capacity(kg/h) | 30-100 | 80-500 | 100-800 | |||
Feed size(mm) | ≤8 | ≤8 | ≤8 | |||
Spindle speed | 0-6700 | 0-5200 | 0-4000 | |||
Dimensions | 1700*1000*1650 | 2500*2000*2500 | 2800*2000*2700 | |||
Detailed Images
Our Service
Pre-Sales Service
* Inquiry and consulting support within 24 hours
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* Engineers available to service machinery overseas.
Product packaging
Packing Size:
It depends.
Packing Weight:
It depends
Delivery Ways:
By shipping/air/land.
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Certifications
Exhibition
Company Profile
Founded in 1989, Jiangyin Fangyuan Machinery Manufacturing Co., Ltd. is located in Zhutang Town, Jiangyin City, the first town of foreign trade in Jiangnan. It is adjacent to Jiangyin Yangtze River Bridge, Shanghai-Nanjing, Xicheng and Yanjiang Expressway. It has a unique geographical location, with Shanghai to the east, Suzhou and Wuxi to the south, Changzhou and Nanjing to the west, and the Yangtze River to the north. Waterway transportation is convenient. The company covers an area of more than 20,000 square meters and has a construction area of 12,000 square meters. It has more than 10 middle and senior technicians and more than 100 employees.
FAQ
Q: How long will you deliver the goods after I place an order?
A: Normally, our delivery time is 30 days after we receive the deposit. If the order is big, we need to extend the delivery time.
Which payment terms can we accept?
1. Normally we can work on T/T term or L/C.
2. On T/T term,30% down payment is required in advance. And 70% balance shall be settled before shipment.
3. On L/C term, a 100% irrevocable L/C without soft clauses can be accepted.
Q: What's the warranty of the products?
A:we offer you one year warranty.
Guarantee & After-sale Services
One year guarantee for whole machine
24 hours technical support by e-mail.
User manual.
Why Choose Us?
7 *24 hours online EMAIL service!
1. We are Alibaba Assessed Gold Supplier.
2. We are a factory with rich experience and technology, engaged in the machinery industry for more than ten years, best quality controland best services.
3. Approved CE, ISO9001.
A: Normally, our delivery time is 30 days after we receive the deposit. If the order is big, we need to extend the delivery time.
Which payment terms can we accept?
1. Normally we can work on T/T term or L/C.
2. On T/T term,30% down payment is required in advance. And 70% balance shall be settled before shipment.
3. On L/C term, a 100% irrevocable L/C without soft clauses can be accepted.
Q: What's the warranty of the products?
A:we offer you one year warranty.
Guarantee & After-sale Services
One year guarantee for whole machine
24 hours technical support by e-mail.
User manual.
Why Choose Us?
7 *24 hours online EMAIL service!
1. We are Alibaba Assessed Gold Supplier.
2. We are a factory with rich experience and technology, engaged in the machinery industry for more than ten years, best quality controland best services.
3. Approved CE, ISO9001.
