VSI/VIS 7611 8518 9526 basalt stone crusher sand stone crusher limeston/limestone fine impact crusher



Product Description


VSI/VIS 7611 8518 9526 basalt stone crusher sand stone crusher limeston/limestone fine impact crusher is also known as sand making machine and shaping machine. It is the internationally advanced low energy crushing equipment which manages the fine crushing equipments for ore, river pebbles and Iron ore. It is the effective, practical and reliable sand shaping machine at this moment.


_20171108110319





Description of the VSI/VIS 7611 8518 9526 basalt stone crusher sand stone crusher limeston/limestone fine impact crusher


This series of sand making  machines are suitable for kinds of hardness material, widely used in metal ore or non_metallic minerals, building sand, stones, metallurgical slag, and quartz. It is especially suitable for super hardness material and wear resistant material such as corundum, sintered bauxite, etc.


kinds of stone


VSI sand maker











Technical data



























































































Model


VSI-7611



VSI-8518



VSI-9526



VSI-1140



Capacity
(t/h)



Center and Sides Feeding



120-180



200-260



300-380



450-520



Center Feeding



60-90



100-130



150-190



225-260



Max. Feeding Size (mm)



Soft Material



35



40



45



50



Hard Material



30



35



40



45



Rotation Speed(rpm)



1700-1890



1520-1690



1360-1510



1180-1310



Double Motor Power (kw)



110



180



264



400



Overall Dimension
L×W×H (mm)



3700×2150×2100



4140×2280×2425



4560×2447×2778



5000×2700×3300



Weight (t)



7.8



10.3



16



25.6



Vibration Sensor



Inspection scope: 0.1-20mm/s continual adjustment



Hydraulic oil pump



Motor Power of Double Oil Pump(Kw)



2×0.31kw



Overall Dimension
L×W×H (mm)



820×520×1270



Power of Oil Tank Heater



2KW






Application of the VSI/VIS 7611 8518 9526 basalt stone crusher sand stone crusher limeston/limestone fine impact crusher


VSI/VIS 7611 8518 9526 basalt stone crusher sand stone crusher limeston/limestone fine impact crusher is widely used in all kinds of mineral, cement, corhart, bauxite chmotte, carborundum grain, glass raw material, machine made construction sand, stone stock and all kinds of metallurgy slag, especially carborundum, sintered bauxite, magnesite, and so on material with features of very hard and anticorrosion.


 5  impact crusher









Application of the PXJ Sand Making Machine


PXJ Sand Making Machine The features of rational combination design of three crushing chambers, novel adjusting mechanism,effective control of uniformity of the product fineness


easy access fir maintenance have made the hammar and screen plates replaced more easily.


01


PXJ





Application of the PC Hammer Sand making machine


This series of sand making machine (hammer crushers) also called hammer mill,is suitable for crushing various hard and brittle materials such as coal, salt, chalk, plaster stone,gypsum, alumstone, brick, tile, limestone etc. Whose compressive resistance does not exceed 150Mpa and the moisture content should not be greater than15%.


3.stone hammer crusher
