Product Overview
Description
The machine can meet the demands of overloading use and stands up to the most severe filed environment. Meanwhile, it also can reduce fuel consumption,which greatly cut down the operation cost. Subsided structure to install the oil tank, placed around each one, Increase oil reserves, make the add oil time interval longer, the weight on both sides are balanced. Tank not in the case, make the space more and not only bring convenience to maintenance service, noise is reduced accordingly, but also giving the customer a good value feeling.
Technical Data
| Name | HG600-8C | HG460-13C | HG550-13C | HG500-13C | HG800-20F | |
| Compressor | displacement (m3/min) | 8 | 13 | 13 | 13 | 20 |
| displacement pressure (bar) | 8 | 13 | 13 | 13 | 20 | |
| compression level | single level | single level | single level | single level | single level | |
| gas tank volume (L) | 130 | 120 | 130 | 120 | 211 | |
| oil volume (L) | 65 | 60 | 65 | 60 | 137 | |
| Disel | manufacturer | east cummins | east cummins | east cummins | east cummins | east cummins |
| model | 6BTA5.9-C180 | 6BTA5.9-C180 | 6BTA5.9-C180 | 6BTA5.9-C180 | 6BTA8.9-C360 | |
| cylinder numbers | 6 | 6 | 6 | 6 | 6 | |
| rated power (kw) | 132 | 132 | 132 | 132 | 264 | |
| rated rotation speed (rpm) | 2200 | 2200 | 2200 | 2200 | 2200 | |
| empty load rotation speed (rpm) | 1400 | 1400 | 1400 | 1400 | 1400 | |
| lubrication oil volume (L) | 18 | 18 | 18 | 18 | 24 | |
| cooling liquid volume (L) | 40 | 40 | 40 | 45 | 60 | |
| oil tank volume (L) | 335 | 335 | 335 | 210 | 550 | |
| main machine | battery | 6-QW-135MF x 2 | 6-QW-135MF x 2 | 6-QW-135MF x 2 | 6-QW-135MF x 2 | 6-QW-135MF x 4 |
| inlet size | 1-G2",1-G1" | 1-G2",1-G1" | 1-G2",1-G1" | 1-G2",1-G1" | 1-G2",1-G1" | |
| transmission way | direct coupling | direct coupling | direct coupling | direct coupling | direct coupling | |
| length (mm) | 4200 | 4200 | 4200 | 3400 | 4080 | |
| width (mm) | 1980 | 1980 | 1980 | 1690 | 2080 | |
| height (mm) | 2210 | 2210 | 2210 | 2200 | 2011 | |
| total weight (kg) | 2700 | 2700 | 2700 | 3200 | 5300 | |
| travelling way | two-wheel move | two-wheel move | two-wheel move | four-wheel move | fixed | |
1. Q: Are you trading company or manufacturer?
A: We are original equipment manufacturer.
2. Q: How long is your delivery time?
A: It is according to the model and quantity.Generally it is 3-5 days if the machines are in stock.It will be 15-30 days if you want to customize the machines.
3. Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer you the sample machine.But it's not free. You need to pay for the sample and the cost of freight.
4. Q: What is your terms of payment?
A: We accept T/T, Western Union, Money Gram, Paypal, Alibaba Escrow etc.Payment<=USD 5000, 100% in advance.Payment>=USD 5000, 30% T/T in advance, balance before shipment.
