Product Overview

Description





Model	Compressor Model	Cooling Capacity(W)	Condenser Fan QTY	Input(KW)	Overall size(mm)
XJQ02MAG-E	ZB15KQE	3080	1	1.82	1020*420&*1240
XJQ03MAG-E	ZB21KQE	4680	1	2.51	1020*420&*1240
XJQ04MAG-E	ZB29KQE	6360	1	3.33	1020*420&*1240
XJQ05MAG-E	ZB.38KQE	8020	2	4.2	1020*420&*1240
XJQ06MAG-E	ZB45KQE	9380	2	4.75	1020*420&*1240
XJQ07MAG-E	ZB48KQE	10200	2	5.23	1020*420&*1240
XJQ08MBG-E	ZB58KQE	12400	1	6.32	967*825*1025
XJQ09MBG-E	ZB66KQE	14000	1	7.05	967*825*1025
XJQ10MBG-E	ZB76KQE	16600	1	8.22	967*825*1025
XJQ13MBG-E	ZB95KQE	20300	2	10.6	1354*825*1025
XJQ15MBG-E	ZB114KQE	24000	2	12.65	1354*825*1025
Power:380V/3P/50HZ   Refrigerant: R404A   Cold room temperature:-15~5℃



Model	Compressor Model	Cooling Capacity(W)	Condenser Fan QTY	Input(KW)	Overall size(mm)
XJQ02LAGY-E	ZSI06KQE	1870	1	1.73	580*380
XJQ03LAGY-E	ZSI09KQE	2640	1	2.21	580*380
XJQ04LAGY-E	ZSI11KQE	3350	1	2.58	580*380
XJQ05LAGY-E	ZSI15KQE	4820	2	3.52	580*380
XJQ06LAGY-E	ZSI18KQE	5900	2	4.29	580*380
XJQ07LAGY-E	ZSI21KQE	6580	2	4.73	580*380
Power:380V/3P/50HZ   Refrigerant: R404A   Cold room temperature:-18~-20℃



Model	Compressor Model	Cooling Capacity(W)	Condenser Fan QTY	Input(KW)	Overall size(mm)
XJQ08LAGY-E	QF125AE	7700	1	5.6	570*785
XJQ12LAGY-E	QF175AE	8800	1	6.6	570*785
XJQ13LAGY-E	QF185AE	10200	1	7.5	570*785
XJQ15LAGY-E	QF205AE	11600	1	8.7	570*785
Power:380V/3P/50HZ   Refrigerant: R404A   Cold room temperature:-18~-30℃





3,Main components:

1.compressor  2.suction and discharge valves 3.oil heating belt 4. condenser 5.liquid receiver

6.Drier and filter 7.sight glasses 8.solenoid valve   9.diaphragm type pressure switch 10.H/L pressure gauge

11.in/out pipe connection valve  12 liquid injection valve 13 enhanced gas injection 14 mechanical type low voltage control   15 mechanical type high voltage control 16 discharge temperature protector  17vibration eliminator  18oil separator  19gas separator

XJQ02H-XJQ05H:item 1,4,5,6,7,8,9,10,11,16;optional:14,15

XJQ08H-XJQ15H:item1,3,4,5,6,7,8,9,10,16;optional:14,15,18,19

XJQ02M-XJQ07M:item1,4,5,6,7,8,9,10,11,16;optional:14,15

XJQ08M-XJQ15M:item1.2.3.4.5.6.8.8.9.10,16;optional:14,15,18,19

XJQ20M-XJQ25M:item1.2.3.4.5.6.7.8.9.10,15,16,17,18;optional:  19

XJQ02L-XJQ07L:item1.2.3.4.5.6.7.8.9.10.11,12,14;optional:15

XJQ08L-XJQ15L:item1.2.3.4.5.6.7.8.10,13,15;optional: 18
