Dongfeng China Compress Garbage Truck Refuse Compactor
Specifications
Item
Specifications
Item
Specifications
Truck
Name
Dongfeng China Compress Garbage Truck Refuse Compactor
Model
CSC5185ZYS6
Gross Weight
18000kg
Overall dimensions
8550*2500*3300mm
Curb Weight
10650kg
Wheelbase
4500mm
Approach angle
18°
Front Track
1862mm
Departure Angle
13°
Rear Track
1806mm
Front Overhang
1260mm
Number of axles
2
Rear Overhang
2790mm
Max speed
105km/h
Number of Tyres
6
Traction system
4×2
Tyre
10.00R20 /275/80R22.5
Transmission
manual
Allowable Cab Passengers
2
Chassis
Model
EQ1185LJ9CDE
Brand
Dongfeng
Drive type
RHD or LHR
Leaf Spring
8/10+7
Fuel type
Diesel
Emission Standard
Euro 5
Upper
Volume
12CBM
Uploading cycling time
<60s
Material
Q235carbon
Loading cycling time
<30s
Thickness
5mm
Operation system
Electrically hydraulic control
Engine (Motor)
Model
Power (kw/h)
Horsepower (hp)
Displacement (ml)
B6.2NS6B210
154
209.44
6200
D4.5NS6B220
162
220.32
4500
D4.0NS6B195
143
194.48
4000
YCS04200-68
147
199.92
4156
CY4SK761
145
197.2
4087
B6.2NS6B230
169
229.84
6200
Equipment
Gearbox
5 forwards & 1 reverse
Steering Gear
Hydraulic steering
Clutch
Reinforced diaphragm clutch
Brakes
Dual circuit compressed air brake
Equipped with dustbin, hydraulic system and operating system Equipped with two advanced double acting hydrocylinders One vehicle can cooperate with several dustbins to improve the ability of cycle operation.cycling time 60s
More imformation
Garbage body Material: 16 Low alloy steel
Garbage boday welding by 8mm,5mm,4mm and 16Mnr steel
Hydraulic system : Electric magnetic valve TG3522-02U
Cylinder :MAL25X50
Combination valve: 34DLS-10-P-0000
Lift bin oil cylinder: HSGK01-63/35-700X450
Push plate oil cylinder : DJG-150III-1150X2170
Scraper plate oil cylinder:HSGK01-80/45-700X300
Sliding plate oil cylinder:DJG-115II-1000X1020
The negative pressure oil cylinder:HSGK01-63/35-500X300
