Product Overview
Description
18w/30w/45w/60w Aluminum Housing Ip55 Led Tube Triproof Light With Emergency Dimmable
Product Description
| General | Name | LED IP55 tri-proof light | |||
| Information | Model No. | BY-LY2-18W | BY-LY2-30W | BY-LY2-45W | BY-LY2-60W |
| Light source | SMD | ||||
| Structure | Detachable modular | ||||
| Chip | 2835 0.2w | ||||
| Warranty | 3 years | ||||
| Electrical Information | Power(W) | 18W/30W45W60W | |||
| Voltage | AC100-277V 50-60Hz | ||||
| Surge protection | 2.5kv | ||||
| Driver efficiency | >90% | ||||
| Power factor | 0.95 | ||||
| Optical Information | Model No. | BY-LY2-18W | BY-LY2-30W | BY-LY2-45W | BY-LY2-60W |
| Product size(CM) | 600*36*41 | 1200*36*41 | 1500*36*41 | 2400*36*41 | |
| Luminous efficacy(lm/w) | 100 | 100 | 100 | 100 | |
| CRI | >80 | ||||
| Color temperature | 3000k/4000k/6500k | ||||
| LED quantity(PCS) | 168 | 336 | 504 | 672 | |
| Beam angle | 120° | ||||
| Mechanical Information | Housing material | Aluminum+Optical PC | |||
| Lens material | PC | ||||
| Ambient temperature | -40℃~50℃ | ||||
| Working temperature | <60° | ||||
| Storage temperature | -40℃~50℃ | ||||
| IP Rating | IP55 | ||||
led linear light
ip65 tri-proof led light
