| Model | C6236H | C6240H | C6250H | C6260H | |
| CH6236F | CH6240F | CH6250F | CH6260F | ||
| CAPACITY | Max.swing over bed | 360mm | 400mm | 500mm | 600mm |
| Max.swing over cross slide | 190mm | 230mm | 330mm | 330mm | |
| Max.swing over gap | 520mm | 560mm | 660mm | 760mm | |
| Effective length of gap | 200mm | ||||
| Center Distance | 750\\1000\\1500\\2000mm | ||||
| Bed Width | 360mm | ||||
| HEADSTOCK | Spindle hole | 52mm | |||
| Spindle nose | ISO-C6 | ||||
| Spindle taper | MT6 | ||||
| Spindle speed(Number) | (9steps)40-1400rpm | ||||
| FEEDS | Longitudinal feeds range | 0.0832-4.66mm/r | |||
| Cross feeds range | 0.048-2.69mm/r | ||||
| Metric threads range | 19kinds 0.25-14mm | ||||
| Inch threads range | 49kinds 2-40inch | ||||
| Moudle threads range | 11kinds 0.5-3.5mπ | ||||
| CARRIAGE | Max.travel of top slide | 95mm | |||
| Max.travel of cross slide | 180mm | 200mm | 250mm | 250mm | |
| Max.size of toolshank | 20*20mm2 | ||||
| TAILSTOCK | Dia.of tailstock sleeve | 65mm | |||
| Taper of tailstock sleeve | MT4 | ||||
| Max.travel of tailstock | 140mm | ||||
| MOTOR | Main drive motor | 4KW | 5.5KW | 7.5KW | |
| Coolant pump motor | 125W | ||||
| PACKING L*W*H | Center Distance(750mm) | 225*115*175cm | |||
| Center Distance(1000mm) | 245*115*175cm | ||||
| Center Distance(1500mm) | 295*115*175cm | ||||
| Center Distance(2000mm) | 345*115*175cm | ||||
| N.W/G.W | Center Distance(750mm) | 1350/1750kg | 1400/1800kg | 1500/1900kg | 1600/2000kg |
| Center Distance(1000mm) | 1450/1850kg | 1500/1900kg | 1600/2000kg | 1700/2100kg | |
| Center Distance(1500mm) | 1600/2000kg | 1650/2050kg | 1750/2150kg | 1900/2300kg | |
| Center Distance(2000mm) | 1750/2150kg | 1800/2200kg | 1900/2300kg | 2050/2450kg | |
Company | Shining Industrial Enterprise(China) Co., Ltd Nantong Brillante Industrial Enterprise Co., Ltd Edward Pearson Machinery (Shanghai) Co., Ltd NANTONG LIANZHONG MACHINE CO., LTD |
Brand | SIECC/EDWARDS PEARSON/HECTMAC |
Website | www.allmachinetool.com |
Video | 1. Rolling https://youtu.be/Fi3tFKSoLlY 2. Press brake https://youtu.be/pyIChKoh1eA 3. Grooving https://youtu.be/pFZh_n3vrss 4. Ironworker https://youtu.be/0O9OeCmu9QI 5. Plasma cutting https://youtu.be/71BKxv6tVB8 |
ek(a)chinasiecc.com ar(a)chinasiecc.com hl(a)chinasiecc.com ajj(a)chinasiecc.com he(a)chinasiecc.com jc(a)chinasiecc.com | |
| |
| |
| |
| |
| |
| |
| |
| |
| |
| |
| |
PACKAGE AND SHIPMENT | |
| |
OVERSEA | |
| |
| |
How about your machine quality?We are worry about the quality.
SIECC is a mature brand in CHINA,through our many years research in technology,our design including structure and detailed sercurity and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are SIECC machines.And where there are our machines,there are good reputation and terminal user satisfaction. | |
Whether the machine price can be more discount
| |
How about your manufactory in CHINA
We welcome your visit to us any time. | |
Do you accept L/C payment term?
| |
