Product Overview
Description
Annealing Tire Binding Wire Dry Wire Drawing Making Machine Manufacturer
Technical Parameter of Dry Type Pulley Dire Drawing Machine,
Structural Features:Simple and practical structure, more competitive price, and suitable for low carbon.
Maximum Diameter of Inlet Wire (mm) | 6.5mm |
Minimum Diameter of Outlet Wire (mm) | 1.8mm |
Maximum Drawing Speed (m/s) | 3.8m/s |
Power of Single Set (KW) | 7.5KW-15KW |
Weight of Single Set (T) | 0.65T |
Technical Parameter of Dry Type Water-cooled Wire Drawing Machine,
Mainly used for 455#to 65# Carbon steel wire rod, it can drawing mentioned wire rod directly without any surface treatment ,certainly Boron carbide coating could be optional. Spiral bevel gear and reduced-speed transmission is adopted, and gear box is equipped with lubricating gear pump to provide effective lubrication for the bearing gear. The sealing structure of the wire drawing can and the water tank is equipped with an umbrella cap, which can effectively prevent the wire drawing powder from entering the return pipe and the water ejection of the wire drawing can. Hopper’s water cooling system functions well and it is convenient to change mould. The water circulation system can effectively dissipate generated heat during drawing, greatly improve the efficiency of production, reduce the loss of die and improve the quality of wire.
Maximum Diameter of Inlet Wire (mm) | 6.5mm |
Maximum Drawing Speed (m/s) | 3-6m/s |
Power of Single Set (KW) | 7.5KW-18.5KW |
Weight of Single Set (T) | 1T |
1300*1500*2200 |
FAQ
Q:Are you manufacture or trading company?
A:We are manufacture. Our factory specialized in this business field since 1985, So we can give you a directly factory competitive price with customized request.
Q:Do you inspect the finished products?
A:Yes,we have QC departmengt.Will inspect the machine before shipping,to ensure there is no problem of the machine.
Q:How about after-sales service process?
A:We supply the detailed instructment and clear labeling in all the connecting place,thus our customers can try to install by themselves.
Surely,special technical engineers supply urgent technical support and consulting,at the same time,we assign the technical engineers to install and debug the machine according to our clients, then our clients will assume round-trip tickets,eating,accommodation costs and ensure they the personal and property safety, and pay 80 salaries per day.
Equipment Program part is life-long maintenance.
Q:How about the quality guarantee?
A:Usually one year. Within one year after the date when the goods reach the destination port if the parts (not including easily damaged parts ) are broken for reasons which are not human, the seller will change the same with a new one free of cost. but the buyer will pay for postage.Surely can be negotiable.
Q:How about the payment term?
A:T/T,L/C,trade assurance,we can all accept.
Q:Do you have import & export right?
A:Yes,we have,so we can export the carton machines to you directly,without any trading company agency.
