30 Gallon Gasoline Engine Driven Reciprocating Truck Bed Air Compressors
- Category: >>>
- Supplier: Yancheng Talos Engine Equipment Co. Ltd.
Share on (62472291102):
Product Overview
Description
Detailed Images
Product Description
30 Gallon Gasoline Engine Driven Reciprocating Truck Bed Air Compressors
Contractor grade two-stage air compressor is engineered for longevity and heavy-duty work on the jobsite. Also, it is designed for use in remote locations that lack electricity.
Belt-driven full cast iron two stage pump features 3 cylinder design for superior cooling.
It can be mounted to your truck bed for added convenience.
Features + Benefits
* Air delivery: 18 SCFM @ 90 PSI, 19.5 SCFM @ 40 PSI
* Powered by a 420cc OHV gas engine with electric start and recoil backup
* Heavy duty cast iron head and oil lubricated two-stage pump
* 30 Gal. ASME certified tank, throttle control and unloader valve
* Cast iron cylinder for long life and durability
* Easy-to-read pressure gauge, shut off pressure switch, ASME certified tank pressure relief valve, and low oil engine shutdown for added safety
* Oil level viewing window and tank drain plug for easy maintenance
* Sturdy steel legs with truck bed mounting holes
* Powered by a 420cc OHV gas engine with electric start and recoil backup
* Heavy duty cast iron head and oil lubricated two-stage pump
* 30 Gal. ASME certified tank, throttle control and unloader valve
* Cast iron cylinder for long life and durability
* Easy-to-read pressure gauge, shut off pressure switch, ASME certified tank pressure relief valve, and low oil engine shutdown for added safety
* Oil level viewing window and tank drain plug for easy maintenance
* Sturdy steel legs with truck bed mounting holes
Key Specs
Model | AC3065 | Brand | Talos Plus | ||
Maximum Pressure | 12.5bar(180psi) | Air Flow Capacity | 18 SCFM@90 PSI, 19.5 SCFM @40 PSI | ||
Compressor Speed | 960RPM | Air Tank Capacity | 30Gal(113L) | ||
Drive | Belt | Tank Type | Horizontal Single | ||
Pump | Cast iron | Stage | Two | ||
Cooling System | Air cooled | Start System | Electric / Recoil Start | ||
Engine Type | OHV, gasoline | Engine Model | T420 | ||
Bore * Stroke | 90 * 66mm | Displacement | 420cc | ||
Stationary | Yes | Engine Idle Control | Yes | ||
Low Oil Protection | Yes | Fuel Capacity | 6.5L( 1.7gal) | ||
Oil Capacity | 1.1L(0.3gal) | Dry Weight | 219kg(483lbs) | ||
Dimension(L*W*H) | 47 - 1/4in x 20 - 7/8in x 40 - 1/16in.(120 x 53 x 102cm) | ||||
Certificate | CE/EPA | Warranty | 1 Year | ||
Packing & Delivery
Plywood box or according to demand.
Lead time: regular 30 days after got deposit.
