JetNet 3705f Industrial 5-port Power Over Ethernet Switch
Four 10/100 TX Ports with Embedded Injector
One 10/100FX Single-Mode / Multi-Mode Fiber Port
15.4W Full Power Delivery per Port
Port Failure
Terminal Block Power Input for Industrial Application.
DC Jack Power Input for External Power Adapter
Architecture
Easy Configuration by DIP Switch
DIN-Rail/ Wall-mounting and Desktop Installation
-10~70°C operating temperature for hazardous environment
JetNet 3705f-w -40~70°C, special order by project request
Product Introduction
JetNet 3705f, the winner of Best Choice of Computex Taipei 2007 Award, is an Industrial switch delivers over UTP/STP cable not only yield a cost-effective and space-saving network, but also improve power utilization and centralize power management. The JetNet 3705f is equipped with 4 injector switch ports, delivers up to 15.4 watts in each port, and one 100FX port forwarding data to the remote end. The JetNet 3705f conforms to IEEE 802.3af Power over Ethernet () standard. The Power Over Ethernet technology can power up enabled powered devices in full capability, e.g. IP surveillance camera, wireless Access Point, VoIP phone set, POS system, industrial sensors, controllers and security card reader. By connecting an external 48VDC power supply, JetNet 3705f is able to perform power and data transmission to send/receive over the same UTP/STP cable in each of the four ports. To meet the requirements of operating under harsh environment, JetNet 3705f uses a robust aluminum case, offers IP31 protection, and supports alarm relay output. The JetNet 3705f provides standard industrial terminal block for the power and alarm relay contact output to alarm any port malfunction or power failure. For the user's convenience, it also provides a DC jack for the traditional AC/DC power adapter.
