China low cost Small CNC metal Lathe Turning Machine Price CK6132
- Category: >>>
- Supplier: Tengzhou Hipow Machinery Co. Ltd.
Share on (62473634587):
Product Overview
Description
Product Description
 |
China low cost Small CNC metal Lathe Turning Machine Price CK6132 |
 |
Main Feature 1.Widening high stability bed 2.Two gear spindle speed,stepless in gear 3.Wider layor board 4.Intergrated automatic lubrication system
|
1. High Precision Machine Body
Strictly Processed Hardened-tempered casting machine body make the lathe perform precisely.
2. High Precision Chuck and spindle hole
1). Standard spindle hole is 40mm ,Spindle Taper:MT4,
3. Precision Tool Post
1). Standard electrical 4 position tool post
2). 6/8 Position electrical or hydraulic tool post can be choosen
4. Reliable Control System
1).Standard : GSK980, KND System,
2).Optional:Fanuc,Siemens,Mitsubishi and other customized system
5. Customized Tail Stock
1).Standard tail stock is manual
2).Hydraulic tail stock can be customized
 |
Model | Specification | CK6132 |
| Max.swing over bed | 330mm |
Max.swing over cross slide | 160mm | |
Center Distance | 500mm | |
Bed Width | 206mm | |
| Spindle hole | 40mm |
Spindle nose | ISO-D4 | |
Spindle taper | MT4 | |
Spindle speed(Variable) | 200-3000rpm | |
| X/Z axis rapid travel speed | 8000/1000mm/min |
X/Z axis cutting travel speed | 1-3000/1-2000mm/min | |
Max.travel of cross slide | 250mm | |
Number of tool post | 4 | |
Max.size of toolshank | 16*16m2 | |
| Dia.of tailstock sleeve | 0.005mm |
Taper of tailstock sleeve | 0.01mm | |
Max.travel of tailstock | 0.001mm | |
| Dia.of tailstock sleeve | 45mm |
Taper of tailstock sleeve | MT3 | |
Max.travel of tailstock | 120mm | |
| Main drive motor | 3KW |
Coolant pump motor | 90W | |
| Center Distance(500mm) | 165*140*170cm |
Center Distance(1000mm) | 215*140*170cm | |
Center Distance(1500mm) | 265*140*170cm | |
WEIGHT (N.W/G.W) | Center Distance(500mm) | 1050/1350kg |
Center Distance(1000mm) | 1250/1600kg | |
Center Distance(1500mm) | 1500/1900kg |
Company Information
 |
Packaging & Shipping
 |
| Packing of exported CNC machine is usually in wooden case. Small CNC machine can be packed in wooden case in whole. |
FAQ
 | |
| Q1. | How can I get a quotation? |
| A. | Leave us massage with your purchase requements and we will reply you ASAP. And you may contact us directly by Trade Manager or Telephone. |
| Q2. | Can you provide customized machine or SPM (Special purpose machine)? |
| A. | Yes, we provide smart CNC solutions for our customer, in order to increase efficiency. |
| Q3. | Can you provide training for operation CNC machines? |
| A. | Yes, free training in our factory is available. |
| Q4. | How about your price? |
| A. | Send me details about what you need, you will get the best price in China. The price is competitive over the world. |
| Q5. | What’s the delivery time, and what’s the package? |
| A. | Normally the delivery time is about 30-45 days. All our CNC machines are packed with sea worthy package. |
