Working temperature: -20-60 degree Supply voltage: DC12-24V Static power consumption: <0.5W Net weight: 220g Overall dimensions: 150 x 78.5 x 26mm/5.9 x 3.09 x 1.02in Output: 5 loop Maximum output current: 20A
Related Products
Packing&Shipping
FAQ
Q: If TC420 or TC421 display "NULL", what should I do? A: NULL means there is not any modes in the controller, please create your mode and download it to the controller, it will not display NULL any more, and display mode name, thanks.
Q: If I want to control my light with my smartphone, how can I do? A: You should buy the controller which work with WiFi connect or Bluetooth Connect function.
Q: If the controller output is lower than my light, how can i do? A: You should have a power amplifier to work with the controller together to get more power output, or connect us to find a similar function controller with higher power output.
Q: If i use a SPI controller or DMX controller, the control distance is too far, then the signal become weak, how can i do? A: you should have a SPI amplifier of DMX distributor to improve the signal strength.
Q: Which voltage controller should I use? A: You can confirm the voltage of your light through the mark on the light, the manual, or the original power voltage, then use the same voltage controller is OK.
Q: What is the different between IR controller & RF controller? A: They are all wireless remote control method, but IR is transfered by invisible infrared ray, it can be prevented by any opaque object, the scope of the application is limited and smaller, the RF is transfered by 2.4GHz signal, can be spreaded further and bypass obstacles, also, IR equipment can be interfered by each other, RF will not.
Q: How can I connect the Pixel light controller, if the voltage of my light is not same with the controller? A: Connect correct power supply to controller and light, then connect the "DATA" and "GND" of controller to light.
