Electric Vehicles 1000V High Voltage CCS Fast Dc Charging Rectifier 20kw

Product Overview

Description



Electric Vehicles 1000V High Voltage CCS Fast Dc Charging Rectifier 20kw

The 20KW 1000V DC output EV charging power module is specially design for the EV DC chargers. It has high efficiency, high power factor, high power density and high reliability advantage. It with 3 phase  285V - 475V AC input,  and DC output voltage form 200VDC to 1000VDC high voltage output, compliant with CE Safety standard.



FEATURES

·Inside high frequency transformer isolation.
·Full hot plug design, easy to install.
·3 phase active power factor correction technology,reduce the harmonic interference to the grid.
·285V - 475VAC input design, allows operationin most poor grid conditions.
·Wide output Voltage option, suitable for wide range of EVs
·Constant current keeps the more power output in lower voltage
·Low Standby power consumption <10W
·High full load efficiency ≥95.5%
·A patent intelligent discharge circuit inside, improve the system reliability and simplify the system design
·Dual DSP design, achieve the full digital control, fewer components means higher reliability
·Wide operating temperature range -40℃ to +75℃
·Compliant with CE Safety standard



TECHNICAL DATA

Electrical Ratings	Input Voltage	285 ~ 475V AC; 3-phase + PE
	Frequency	45Hz - 55Hz
	Power Factor	≥ 0.99 (Full Load)
	Output Power	20KW
	Output Current	80A (Max limit current is 80A, limit current point can be set between 2~80A)
	Output Voltage	200 - 1000V DC
	Super Wide Constant power output Voltage range	250 ~ 500VDC, 500 ~ 1000VDC
	Efficiency	>95.5% (Full Load)
	Voltage stabilization Accuracy	≤ ±0.5%
	Current stabilization Accuracy	≤ ±1% (20% to 100% load)
	THD	≤ 5% (More than 50% load)
Communication	Protocol	CAN
Environmental Ratings	IP protection level	IP20
	Working Temperature	Operating temp:-40~50℃ (≥55℃ with limitation power output)
	EV Charging Rectifier Cooling Method	Fan cooling



Input voltage / output power curve

Output voltage / output current curve



COMPANY INFORMATON

SENKU MACHINERY is a professional EV charging solution supplier of electric vehicle components,including all kinds of EV charging connectors (plugs&sockets), EV charging cables, EV charging Adapter, EV charging stations...The products got the certification of UL, TUV, ETL, CE. And the products were sold to Brazil, U.S.A, Italy, Switzerland, Germany, UK, France, Romania, Sweden, New Zealand, Slovakia, Czech Republic, Russia, Korea, Japan, India, Vietnam, Kazakhstan etc...

With rich experience and research institutions, advanced equipment and professional technical teams, SENKU MACHINERY can design, produce, develop and provide high quality products for enterprises and clients, by taking advantages of abundant industrial resources and extrusive influential, SENKU MACHINERY carries out consultations services related to products, technologies, market and projects.

Professions cast the brand, service creating value. SENKU MACHINERY sincerely to build long terms relation ship with clients, Vigorously Developing, Win-Win in the world!



RFQ

Q1. What is your terms of packing?

Generally, we pack our goods in neutral cartons. Brand Customized Service Support.

Q2. What is your terms of payment?

Quantity order amount >=10000USD,30% as deposit, and 70% before delivery.

Quantity order amount <10000USD, 100% as deposit.

We' ll send you the pictures of the goods and packages before you pay the balance.

Q3. What is your terms of delivery?

EXW, FOB, CFR, CIF, DAP.

Alibaba order acceptable

Q4. How about your delivery time?

Generally, it will take 7-12 days after receiving your advance payment.

The specific delivery time depends on the stock and order quantity.

Q5. What is your sample policy?

Sample order acceptable, but the customers have to pay the sample cost and the courier cost.

Q6. Do you test all your goods before delivery?

Yes, we do 100% test before delivery.



More details please contact our sales, Get in touch with us to experience quality products and services now!!!
