Intel skylake 3855u 8 LAN firewall motherboard with 2 SFP for network security router

Share on (62476639261):


Price:

Quantity:


Product Overview

Description


Intel skylake 3855u 8 LAN firewall motherboard with 2 SFP  for network security router

1.intel 3855u processor embedded

2. 1*sata 3.0 1*m.2 sata 1*mini-sata

3. 8*1000M lan 2*SFP  DDR4 ram socket

4.vga header com header 1*LAN to Com

5.solution for firewall computer router














Product Description





Processor

  CPU

Intel skylake 6th gen 3855u

  Frequency

Dual core 1.6g

  Chipset

SOC

   TDP

15W

Memory

  slot

1*SO-DIMM,DD4 1600HZ

  Capacity

MAX to 16GB



Storage



  connectors

1*SATA3.0 1*Mini-SATA  1*M.2 SATA

1*M.2 connector for SATA

1*SIM

Display

 chipset

HD integrated

  connector

VGA header

LAN

  chipset

3*Intel i350

  connector

8*RJ 45 1000m  2*SFP

Audio

  chipset

 NA

  connector









I/O

  com

2*com(1*RJ45 to com )

  lPT



  USB

2*USB3.0,2*USB2.0 header(expand to 4*USB2.0 connectors)

  GPIO

1*GPIO

  Header



1*F-PANEL

1*PS/2

2*F-USB 2.0

1*CPU-FAN

1*CLR-CMOS

1*AUTO-ON  1*GPIO

1*COM  1*12V ATX

1*VGA  1*CLR-CMOS



Power

  power supply

1*DC IN 12V/4 PIN ATX

OS



Win7/win8/WIN10/linux

BIOS



AMI BIOS 64BIT



Working environment

  working temp

-10~60degree

 storage temp

-10-70 degree

  Relative  humidity

5%-95% non-condensing

Form factor

  Size

230*230mm





Packaging & Shipping

 Carton box : 20pcs/ carton  15kgs/carton

Shipping by Air or express . you can reveive the cargo in 5-15 days



Our Services

We can give you 1 year warranty

To assure the quality, we usually do full test befor shippment to avoid the quality issue

24*7 hotline for inquiry, if you have any questions about our products, you can contact us any time.



Company Information

 Plant

FAQ



1.What is your payment terms ?
T/T Paypal westunion money gram for sample or small order

2.What is your lead time?
3-5 working days after receipt of payment

3.Do you have warranty about your products?
Yes, 1 year

4. Can you do customlized serive ?
Yes. We can add your logo on our products. or we can design as per your requirements
OEM and ODM serive are available
