8mm thick plate Hydraulic thick plate cnc turret punching machine hole punch machine
- Category: >>>
- Supplier: Nantong Tengzhong Machinery Co. Ltd.
Share on (62483628536):
Product Overview
Description
product description
8mm thick plate Hydraulic thick plate cnc turret punching machine hole punch machine
| Name | Parameter | Unit | Remark | |
| 1 | Punching press | 300(30) | (KN)T | |
| 2 | Rack structure | "O" type closed servo drive | ||
| 3 | Maximum processed sheet size | X-axis 2500 | mm | Secondary positioning can process 5000mm |
| Y-axis 1250 | mm | |||
| 4 | Maximum processed plate thickness | 6.35 | mm | |
| 5 | Maximum diameter of one punch | 88.9 | mm | Non-standard custom-made |
| 6 | Maximum hit speed | 280 | hpm | |
| 7 | Controlled axes | 3/4 (X,Y,T,Z) | ||
| 8 | Mould form | Long guide 85 series international standard mould | ||
| 9 | Turret station distribution | A B C D | Non-standard custom-made | |
| 10 | Repositioning cylinder | 2 | Set | |
| 11 | Maximum feeding speed | X-axis 80 | m/min | |
| Y-axis 80 | m/min | |||
| 12 | Operating platform structure | Brush / Universal steel ball composite table | Stainless steel edging | |
| 13 | Turret speed | 40 | rpm | |
| 14 | Machining accuracy | ±0.1 | mm | |
| 15 | Maximum load weight | 150 | Kg | |
| 16 | Max output power | 15.5 | KW | |
| 17 | Air pressure | 0.55 | MPa | |
| 18 | Electric source | 380±5% | V | |
| 19 | Mould service life | 50 | ||
| 20 | Outline size | 5000*5000*2100 | mm |
Company Information
hot product
FAQ
FAQ
Q: GUARANTEE PERIOD
A: Our product quality guarantee period is 12 months from B/L date. During guarantee period, we will provide spare parts without
any charge in case of quality discrepancy caused by us. If the malfunctions is caused by customers' incorrect operation, we will provide spare parts at cost price. We can also offer flexible extended warranties according to the actual situation.
Q: AFTER-SALES SERVICES
A: Our engineer can go to your factory for installation and show operation details on condition of you provide the round-trip air tickets, visa formalities, food and accommodation. In turn, your engineers can come to our factory for learning the installation, operation and maintenance for free.
Q: WHY CHOOSE US
A: 15 years machine exporting experience, give customer prompt after service feedback .
Self manufactured machine, quality strictly control. OEM service.
Q: What is your payment terms?
A:T/T,L/C, Western union and so on.
Q: How to operate your machine?
A:We will provide operational manual along with the machine, we can also send operation vedio for study. Face to face on line teaching is also available.
Q: How to choose a model?
A:Send us your plate material, max thickness, max width then we can give you suggestion.
Q: How long is your production time?
Normally standard model delivery time is 30 working days, for bigger model we will need 45 or 50 working days. For urgent order,we can finish at 15 days. Need to discuss by each order.
Q:Do you test your machine before delivery?
A: Every machine will need 24 hours running,then engineer debug before packing.
