Fully Automatic Horizontal Wine Box Bubble Pressing Machine
- Category: Bubble Toys >>>
- Supplier: Guangdong Lishunyuan Intelligent Automation Co. Ltd.
Share on (62485044092):
Product Overview
Description
Product Description
Full-automatic horizontal bubble press, use the mechanical arm sucker to suck the wine box into the box pressing station. After pressing the box, the same mechanical arm sucker will suck the wine box out of the pressing station and enter the next process. the equipment does not need manual, high efficiency, The man-machine system adopts touch screen interface, which is convenient to set up.
Technical Parameters
Working speed | 0-25Min |
Air pressure | 1.0-1.6mpa |
Total power | 2KW |
Power supply | 220V/50Hz |
Min. pressing dimension | 105*105*120mm |
Max. pressing dimension | 200*200*320mm |
Machine dimension | 4200*1700*1500mm |
Machine weight | 600kg |
Product features
1、The equipment does not need labor and has high efficiency. Under the pressure from all sides, the box body will not deform and collapse in the slightest, and the size will increase by 2.5 mm on one side to 5 mm in total.
2、The die core is designed as a structure with simultaneous expansion on all sides. The expansion force is symmetrical and the size is accurate. It will not allow the box body to deform and size is collapse in the slightest. The expansion 2.5 mm on one side and 5 mm in total.
3、100 mm-180 mm wide x 200 mm-320mm high wine box surface with external template can be adjusted in size.
4、The control circuit is designed with machine adjustment, operation and manual operation, each group of cylinders can be started separately, and the pressing box is delayed, etc.
5、The man-machine system adopts touch screen interface, which is convenient to set up.
2、The die core is designed as a structure with simultaneous expansion on all sides. The expansion force is symmetrical and the size is accurate. It will not allow the box body to deform and size is collapse in the slightest. The expansion 2.5 mm on one side and 5 mm in total.
3、100 mm-180 mm wide x 200 mm-320mm high wine box surface with external template can be adjusted in size.
4、The control circuit is designed with machine adjustment, operation and manual operation, each group of cylinders can be started separately, and the pressing box is delayed, etc.
5、The man-machine system adopts touch screen interface, which is convenient to set up.
Workshop
Workshop Office Area
Partial Install Area
Packing&Shipping
Film and plywood crate.
After Sales Service
Quality after-sales service
1、We will reply to your service request call within one hour with solution.
2、The GM's office will handle customer's complaints directly and reply within 12 hours with solution.
3、The maintenance team will be in place within 24 working hours for customers located within 500km of the service point range.
4、By re-visiting the customers on a monthly basis ,customers can rest assured and worriless.
Company Introduction
LiShunyuan was founded in 2001, located in Dongguan city, Guangdong Province Daojiao town Nanya Industrial zone, and has a modern standard workshops of 20000 square meters, after 17 years of development, the company in domestic has formed a complete sales network and after-sales service system, product sales network and after-sales service system, product sales throughout the whole of China, exported to Europe and the united states, Southeast Asia, South America, Middle East, Africa and so on more than 40 countries and Regions.
Innovation is the core competitiveness of Lishunyuan. The company owns independent intellectual property products including rigid box series, clamshell box series,widely used in the production of gift boxes, mobile phone boxes, cosmetic boxes, liquor & wine boxes , and other boutique boxes.
Lishunyuan adheres to the development concept of “customer first, service to the world” and adheres to the development strategy of “keep improving and bring forth the old and new”. Lishunyuan devotes itself to the development of new products with high performance and high efficiency in the industry and leads the rapid development of intelligent automation in the industry.
Innovation is the core competitiveness of Lishunyuan. The company owns independent intellectual property products including rigid box series, clamshell box series,widely used in the production of gift boxes, mobile phone boxes, cosmetic boxes, liquor & wine boxes , and other boutique boxes.
Lishunyuan adheres to the development concept of “customer first, service to the world” and adheres to the development strategy of “keep improving and bring forth the old and new”. Lishunyuan devotes itself to the development of new products with high performance and high efficiency in the industry and leads the rapid development of intelligent automation in the industry.
Our Services & Strength
We have competitive machines, the quality team and the thoughtful service. Lishunyuan emphasizes on giving complete support to our customers, from consultation and development of the machine as per client requirements, to production of the box machine and providing extensive after sales service.Dedicated to providing the highest production rates, maximum accuracy and consistent pouch quality of boutique boxes as per each individual client’s requirements.
