Product Overview

Description



GT Detector Keyboard Switch
* Features
- Tight Configuration,Small Contact Gap , Snap Action
- Long Life, High Reliability
- Global Safety Approvals
- Variety of Terminals
- Wide Range Operating Force
- Wide Range Temperature Grade
- With Optional PTI Grade
- Variety Used in Home Applicances, Electronic Equipments, Automatic Machines,
Communication Equipments.


Products Description




Application
Home Applicances
Electronic Equipments
Computer keyboard Money Counter
Automatic Machines
Communication Equipments
Cash Registers


Product Parameters





Electrical
Characteristics
Rating
12VDC/AC max. 10mA AC/DC max

Contact Resitance
200MΩmax (25MΩtypical)(initial value)

Insulation Resistance
100MΩMin
Voltage Resistence
AC 100V (50-60Hz) 1Minute
Eletrical life
Over 50,000,000 cycles (Load)
Bounce Time
400mm/s 5msec (operation speed at 400mm/spec)




Parameters
Operating Force
See Detail Spec
Pre-travel
2.0±0.6mm
Total Trave
4.0±0.4mm
Mechanical Life
Over 80,000,000 cycles (No Load)
Operating Temperature Range
-40℃~ + 80℃
Ambient Humidity
≤85%RH max




Related Products




Company Information


Our Advantage
1.30 years manufacture experience
2.OEM is available: material,size and other requirements are customized
3.Our laboratory is certified by SGS,TUV
4.ALL of our goods have acquired TUV,CE,SEMKO,ENEC,CQC certification
5.We use 3D software UG to design and develop our products




Our Exhibition


We have to participate in famous electrical exhibitions all over the world every year.
2019 Micro Switch in India Electronic & Smart Appliances Expo
HongKong-Electronics-Fair
2019 Micro Switch Indonesia Electronics Fair Micro Switch Shanghai Exhibition-Day 1 Chengdu International Auto Parts Exhibition Company in March 9th -3 11 in Shanghai New International Exp
Company Information


Packing&Shipping






FAQ


Q1: Are you a trading company or manufacturer?
A: yes.we are an original manufacturer specializing in micro switches over 30 years.

Q2: What is your MOQ?
A:Normally,We have only accept the MOQ is 100pcs and we will provide 5-10 pcs free sample for your testing before order, pls contact us to know more.

Q3: what is the warranty time?
A: It is about 1-2 years.

Q4: Could you offer us free samples?
A: yes, Afrer the certain design or items is confirmed,free samples could be provided within 2-5 days.

Q5. what is the leading time of mass production?
A: About 2-4 weeks.

Q6: what is the capacity per month?
A:It is over 8 million pieces per month for micro switch series,and over 20 million pieces per month for keyboard switch series.
